Amplifier Research 100S1G2Z5A
| Attribute | Value |
|---|---|
| Frequency Range | 1 GHz – 2.5 GHz |
| Minimum Output Power | 100 Watts CW |
| Gain | 50 dB minimum |
| Gain Flatness | ±3 dB maximum |
| Input for Rated Output | 0 dBm maximum |
| Input VSWR | 2.0:1 maximum |
| Output VSWR | 2.0:1 maximum |
| Harmonic Distortion | -20 dBc maximum at rated output |
| Power Requirements | 220 VAC, Single Phase, 50/60 Hz |
| Cooling Method | Forced air cooling |
Amplifier Research 100S1G2Z5A Options:
- 100S1G2Z5A - M1 - N female RF input and output on rear panel
- 100S1G2Z5A - M2 - Same as 100S1G2Z5A with enclosure removed for rack mounting (N female front)
- 100S1G2Z5A - M3 - Same as 100S1G2Z5AM1 with enclosure removed for rack mounting (N female rear)
| Model | 100S1G2Z5A |
|---|
The Amplifier Research 100S1G2z5A is a solid state, broadband, air‑cooled RF amplifier providing 100 watts minimum output across multiple frequency bands. It features advanced RF input leveling, over‑temperature protection, and a digital control panel with LCD touch screen and remote interface support including GPIB, RS232, USB, Ethernet, and fiber optic connectivity.
Designed for EMC testing, wireless communications, antenna and component evaluation, and frequency multiplication, the 100S1G2z5A ensures reliable high‑gain performance with excellent linearity and low spurious output signals.
Testwall can supply the used Amplifier Research 100S1G2z5A, fully tested. With expert support and global delivery, Testwall ensures high‑performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Amplifier Research 100S1G2z5A.
