Amplifier Research 175S1G6
| Attribute | Value |
|---|---|
| Frequency Range | 0.8 GHz – 1 GHz |
| Output Power (CW) | 175 Watts minimum |
| Gain | 50 dB minimum |
| Gain Flatness | ±2.5 dB maximum |
| Input for Rated Output | 0 dBm typical |
| Input VSWR | 2.0:1 maximum |
| Output VSWR | 2.0:1 maximum |
| Harmonic Distortion | -10 dBc maximum at rated output |
| Power Requirements | 220 VAC, Single Phase, 50/60 Hz |
| Cooling | Forced air cooling |
| Model | 175S1G6 |
|---|
The Amplifier Research 175S1G6 is a solid-state RF amplifier delivering approximately 175 W of continuous output power across a wide 1 GHz to 6 GHz frequency range. Engineered with low distortion and stable gain, it ensures precise performance for demanding high-frequency applications. Built for reliability, this amplifier integrates seamlessly into automated systems, supporting extended and consistent operation.
With its broad frequency coverage, the 175S1G6 is perfectly suited for radar testing, satellite communication, and advanced high-bandwidth experiments. Its dependable output makes it a versatile choice for laboratory and field applications alike.
Testwall can supply the used Amplifier Research 175S1G6, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Amplifier Research 175S1G6.
