Amplifier Research 5000A250A
| Attribute | Value |
|---|---|
| Frequency Range | 10 kHz – 250 MHz |
| Output Power | 5000 Watts (CW) |
| Gain | 63 dB minimum |
| Input Power for Rated Output | 100 mW (20 dBm) maximum |
| Harmonic Distortion | -10 dBc typical at rated output |
| Input VSWR | 2.0:1 maximum |
| Output Impedance | 50 Ohms |
| Input Connector | Type N Female |
| Power Requirements | 208/240 VAC, 3-phase, 50/60 Hz |
| Cooling | Forced air (internal blower) |
| Model | 5000A250A |
|---|
The Amplifier Research 5000A250A is a broadband solid-state amplifier delivering approximately 5 kW CW across the 100 kHz to 250 MHz frequency range. Designed with parallel MOSFET push-pull arrays, it minimizes distortion while ensuring high output power stability. It features a Digital Control Panel for local control, advanced remote interfaces including GPIB, RS-232, and fiber, as well as internal leveling (ALC) and sample outputs. Safety interlocks and facility-class integration make it ...
This amplifier is ideal for large-scale EMC immunity systems, high-power antenna feeds, and heavy-duty test benches. It requires three-phase mains and advanced cooling to support continuous high-power operation, making it a reliable choice for critical RF environments.
Testwall can supply the used Amplifier Research 5000A250A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Amplifier Research 5000A250A.
