Anritsu
Anritsu 54100A
Scalar Network Analyser
DC to 50 GHz Frequency Range
10 ps/div to 100 ms/div Timebase Range
7.5 ps (typical) Rise Time
50 GHz Bandwidth
2 channels (expandable to 4) Number of Channels
| Attribute | Value |
|---|---|
| Frequency Range | DC to 50 GHz |
| Timebase Range | 10 ps/div to 100 ms/div |
| Rise Time | 7.5 ps (typical) |
| Bandwidth | 50 GHz |
| Number of Channels | 2 channels (expandable to 4) |
| Vertical Resolution | 8-bit ADC |
| Input Impedance | 50 Ohms |
| Maximum Input Voltage | ±2V DC + Peak AC |
| Sampling Rate | Equivalent-time sampling up to 1 TSa/s |
| Display | Color LCD display with graphical user interface |
Anritsu 54100A Options:
- 54100A - Option 1 - Rack mounting with slides
- 54100A - Option 2 - 70 dB RF step attenuator
- 54100A - Option 2A - 70 dB, 20 GHz MW step attenuator
- 54100A - Option 2B - 70 dB, 26.5 GHz MW step attenuator
- 54100A - Option 2C - 70 dB, 40 GHz MW step attenuator
- 54100A - Option 2D - 70 dB, 50 GHz MW step attenuator
- 54100A - Option 4 - 75 Ω source output (available to 3.0 GHz)
- 54100A - Option 5 - Add reference channel
- 54100A - Option 6 - Add external levelling
- 54100A - Option 7 - Internal distance-to-fault software
- 54100A - Option 8 - Internal relative group delay software
- 54100A - Option 12 - Add front panel cover
- 54100A - Option 13 - Add front mounted handles
- 54100A - Option 16 - +15 V DC supply for millimeter wave source modules (available with <20 GHz models only)
- 54100A - Option 25 - Maintenance manual
- 54100A - Option 26 - Extra operation and GPIB programming manual
- 54100A - Option 33 - Canon printer
| Model | 54100A |
|---|
The Agilent 54100A is a 1 GHz, 2-channel digital oscilloscope offering 10 ps time resolution, 40 MSa/s digitizing rate, and 10-bit vertical resolution with averaging. Each channel includes 1k memory, making it highly effective for precise analog and digital signal analysis.
Engineers can rely on the Agilent 54100A for high-speed measurements across research, design, and testing applications where both accuracy and bandwidth are essential.
Testwall can supply the used Agilent 54100A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Agilent 54100A.
