Anritsu MA2481A
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 18 GHz |
| Power Range | -70 dBm to +20 dBm |
| Sensor Type | Diode Power Sensor |
| Connector Type | 2.92 mm (K-type) Male |
| Dynamic Range | 90 dB |
| Impedance | 50 Ohms |
| VSWR (Maximum) | 1.20 (10 MHz to 18 GHz) |
| Operating Temperature | 0°C to +55°C |
| Interface | Compatible with Anritsu ML2430A Series Power Meters |
| Calibration Factor | Stored in sensor memory (EEPROM) |
Anritsu MA2481A Options:
- MA2481A - MA2480/01 - Adds fast CW mode to Universal Power Sensors for high speed measurements of CW signal plus TDMA and pulse measurements
| Model | MA2481A |
|---|
The Anritsu MA2481A is a universal diode sensor designed for ML2430-series power meters, covering frequencies from 10 MHz to 6 GHz with a dynamic range of –60 dBm to +20 dBm. It offers typical linearity of ~3% CW, improved to 1.8% CW with option 01. Equipped with an N(m) connector, it ensures reliable performance with a maximum SWR of <1.90.
Compact and versatile, this wideband sensor supports CW and modulated signals, providing accurate measurements across diverse RF applications. Its built-in calibration memory enhances efficiency in field and laboratory use.
Testwall can supply the used Anritsu MA2481A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MA2481A.
