Anritsu MF2414B
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 14 GHz |
| Frequency Resolution | 1 Hz |
| Measurement Time | Minimum 2 ms (reciprocal counting method) |
| Input Impedance | 50 Ohms |
| Input Sensitivity | -20 dBm to +20 dBm (100 MHz to 14 GHz) |
| Maximum Input Power | +30 dBm (1 W) |
| Timebase Aging Rate | ±1 x 10⁻⁸/day (standard TCXO) |
| Display | Fluorescent display, 12-digit numeric readout |
| Power Supply | AC 100/120/220/240 V ±10%, 50/60 Hz |
| Operating Temperature Range | 0°C to +50°C |
Anritsu MF2414B Options:
- MF2414B - 01 - Crystal oscillator (5 x 10⁻⁹/day aging rate)
- MF2414B - 02 - Crystal oscillator (2 x 10⁻⁹/day aging rate)
- MF2414B - 03 - Crystal oscillator (5 x 10⁻¹⁰/day aging rate)
| Model | MF2414B |
|---|
The Anritsu MF2414B is a wide-frequency power sensor designed for precision RF power measurements, covering a frequency range from 10 MHz to 40 GHz. It ensures excellent measurement accuracy and repeatability, making it ideal for demanding RF system testing applications requiring peak and average power detection.
Optimized for use with Anritsu ML2430 series meters, the Anritsu MF2414B supports both peak and average power measurement, offering versatility in advanced RF testing scenarios.
Testwall can supply the used Anritsu MF2414B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MF2414B.
