Anritsu MG3672A
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 20 GHz |
| Output Power Range | -130 dBm to +13 dBm |
| Frequency Resolution | 0.01 Hz |
| Phase Noise | -115 dBc/Hz at 10 kHz offset (typical) |
| Modulation Types | AM, FM, Phase Modulation, Pulse Modulation |
| Output Connector | Type-N Female (50 Ohm) |
| Frequency Switching Speed | Less than 10 ms (typical) |
| Reference Frequency | 10 MHz internal/external reference |
| Power Supply | 100–240 VAC, 50/60 Hz |
| Interface | GPIB, RS-232 |
| Model | MG3672A |
|---|
The Anritsu MG3672A is a versatile digital modulation signal generator covering approximately 300 kHz to 3 GHz, designed for wireless and cellular applications. It supports key standards including W-CDMA, GSM, and EDGE, and integrates a quadrature vector modulator ensuring clean spectral output and minimal distortion. Expansion slots allow additional modulation formats such as CDMA and 3GPP-defined uplink/downlink waveforms.
With low-distortion vector modulation, programmable digital patterns, bit error injection, and flexible waveform generation, the Anritsu MG3672A is ideal for R&D and production testing of base stations and mobile devices.
Testwall can supply the used Anritsu MG3672A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MG3672A.
