Anritsu MG3692A
| Attribute | Value |
|---|---|
| Frequency Range | 2 GHz to 20 GHz |
| Frequency Resolution | 0.001 Hz |
| Output Power Range | -110 dBm to +20 dBm (typical) |
| Phase Noise (at 10 GHz, 10 kHz offset) | -110 dBc/Hz (typical) |
| Spectral Purity | Low harmonic and spurious outputs for high signal integrity |
| Modulation Capabilities | AM, FM, Phase Modulation, and Pulse Modulation |
| Switching Speed | Less than 5 ms (typical) |
| Reference Frequency | Internal 10 MHz reference; external reference input supported |
| Interface/Connectivity | GPIB (IEEE-488) and RS-232 remote control interfaces |
| Power Requirements | 90–265 VAC, 47–63 Hz, 200 W maximum |
Anritsu MG3692A 2-20GHz Synthesised CW Generator Options:
- MG3692A - 12 - Frequency And Phase Modulation
- MG3692A - 13 - External Pulse Modulation
- MG3692A - 13A - External Pulse Modulation
- MG3692A - 14 - Amplitude Modulation
- MG3692A - 15A - High Power
- MG3692A - 16 - High Stability Time Base
- MG3692A - 17 - Delete Front Panel
- MG3692A - 18 - Mmw Bias Output
- MG3692A - 1A - Rack Mount With Slides
- MG3692A - 1B - Rack Mount Without Slides
- MG3692A - 2 - Step Attenuator
- MG3692A - 20 - Scan Modulation
- MG3692A - 22 - 0.1 HZ To 10 MHZ Audio Coverage
- MG3692A - 23 - Lf Generator
- MG3692A - 2A - Mechanical Step Attenuator
- MG3692A - 2F - Electronic Step Attenuator
- MG3692A - 3 - Ultra Low Phase Noise, Main Band
- MG3692A - 4 - 10 MHZ To 2.2 GHZ Rf Coverage (Ultra Low Phase Noise)
- MG3692A - 5 - 10 MHZ To 2 GHZ Rf Coverage
- MG3692A - 9K - Rear Panel Output
| Model | MG3692A |
|---|
The Anritsu MG3692A Synthesised CW Generator offers a frequency range from 2GHz to 20GHz, with 0.01Hz frequency resolution and 0.01 dB output power resolution. It includes options for LF coverage, low phase noise, high output power, and a step attenuator. Featuring ultra-low SSB phase noise and spurious, it is built on the reliable El Toro platform with over 49,000 hours MTBF.
Ideal for high-performance RF testing, the MG3692A supports a sleek front panel, 1/4 VGA LCD, and reduced depth and weight, providing practical usability and advanced capabilities.
Testwall can supply the used Anritsu MG3692A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MG3692A.
