Anritsu MG3696B
| Attribute | Value |
|---|---|
| Frequency Range | 2 GHz to 67 GHz |
| Output Power Range | +20 dBm to -20 dBm (typical, varies by frequency) |
| Frequency Resolution | 0.001 Hz |
| SSB Phase Noise | -80 dBc/Hz at 10 kHz offset (at 10 GHz, typical) |
| Frequency Switching Speed | Less than 10 ms (typical) |
| Harmonics | -20 dBc (typical, above 2 GHz) |
| Non-Harmonics / Spurious | -60 dBc (typical) |
| Modulation Types | AM, FM, Phase Modulation, Pulse Modulation |
| Interface / Connectivity | GPIB (IEEE-488), RS-232 |
| Power Requirements | 100–240 VAC, 47–63 Hz |
| Model | MG3696B |
|---|
The Anritsu MG3696B microwave signal generator delivers outstanding RF and microwave performance with a frequency range from 2 to 67 GHz. It provides maximum output power up to +23 dBm at 20 GHz, with exceptional -94 dBc/Hz phase noise at 1 kHz offset. Offering fast 5 ms switching speed, 0.01 Hz resolution, and adjustable phase offset in 0.1° steps, this high-performance generator ensures precise measurements while reducing test times significantly.
Designed for demanding applications, the MG3696B offers advanced spectral purity, fast modulation, 20 presettable CW frequencies, and flexible 10 MHz reference output. Its compact design and reliability make it suitable for R&D, manufacturing, and repair environments.
Testwall can supply the used Anritsu MG3696B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MG3696B.
