Anritsu MP0110A
| Attribute | Value |
|---|---|
| Function | Optical Modulation Analyzer (OMA) |
| Wavelength Range | 1480 nm to 1620 nm |
| Modulation Formats Supported | DP-QPSK, DP-16QAM, DP-64QAM, and other coherent modulation formats |
| Symbol Rate | Up to 64 Gbaud |
| Optical Input Power Range | -20 dBm to +10 dBm |
| Polarization Diversity | Built-in polarization diversity coherent receiver |
| Interface | USB, GPIB, and Ethernet (LAN) |
| Display | Constellation diagram, eye diagram, and waveform analysis display |
| Operating Temperature | 0°C to +40°C |
| Power Supply | AC 100 V to 240 V, 50/60 Hz |
| Model | MP0110A |
|---|
The Anritsu MP0110A is a bit‑error rate (BER) test module designed for use with Anritsu multipurpose digital link analyzers. It enables BER testing across STM‑1 to STM‑64 (OC‑192) circuits, with customizable error generation, alarm simulation, configurable mark ratio, and pseudo‑random pattern injection. This unit supports synchronization with external clock recovery sources and provides real‑time error logging with threshold alerting, making it ideal for advanced telecom validation and manufacturing environments.
The MP0110A integrates seamlessly with Anritsu multiplexer and transport systems, allowing engineers to inject patterns, monitor alarm thresholds, and assess link performance under controlled conditions.
Testwall can supply the used Anritsu MP0110A, fully tested. With expert support and global delivery, Testwall ensures high‑performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MP0110A.
