Anritsu MP1609A
| Attribute | Value |
|---|---|
| Bit Rate | Up to 12.5 Gbit/s |
| Data Pattern | PRBS (2^7-1, 2^10-1, 2^15-1, 2^23-1, 2^31-1) and programmable word patterns |
| Output Amplitude | 0.5 V to 2.0 V (into 50 Ω) |
| Output Impedance | 50 Ω |
| Rise/Fall Time | Less than 30 ps (20% to 80%) |
| Jitter | Less than 5 ps RMS (intrinsic) |
| Clock Source | Internal or external clock reference |
| Interface | GPIB (IEEE 488.2) for remote control |
| Operating Temperature | 0°C to +50°C |
| Power Supply | 100 to 240 VAC, 50/60 Hz |
| Model | MP1609A |
|---|
The Anritsu MP1609A is a high-performance signal integrity testing module designed for the MP1600 series platform. It supports transmission and reception for 56G/112G PAM4 signals, making it ideal for CEI, PCIe, and Ethernet standard validation. The module enables advanced equalization and jitter tolerance testing with real-time eye diagram monitoring.
This unit is particularly effective for engineers and researchers working with high-speed electrical interfaces, delivering precise compliance analysis and seamless integration with automation tools for streamlined workflows.
Testwall can supply the used Anritsu MP1609A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MP1609A.
