Anritsu MP1810A-015
| Attribute | Value |
|---|---|
| Bit Rate | Up to 14.05 Gb/s |
| Output Amplitude | 0.5 V to 2.0 V (into 50 Ω) |
| Pattern Length | 2^7-1 to 2^31-1 PRBS, programmable word patterns |
| Interface Type | Option 015: 15-pin D-sub connector interface |
| Clock Input Frequency Range | 100 MHz to 14.05 GHz |
| Output Rise/Fall Time | Less than 30 ps (20% to 80%) |
| Jitter (RMS) | Less than 1.5 ps RMS |
| Operating Temperature | 0°C to +50°C |
| Power Supply | AC 100 V to 240 V, 50/60 Hz |
| Dimensions (W × H × D) | 426 mm × 177 mm × 451 mm (4U half-rack) |
| Model | MP1810A-015 |
|---|
The Anritsu MP1810A-015 is a plug-in module designed for advanced error detection in high-speed digital communication systems. It features an integrated bit error detector, real-time BER monitoring with error location mapping, and configurable detection thresholds. The unit seamlessly synchronizes with pattern and clock generators, ensuring precise validation of complex signals in telecom and datacom equipment testing.
This module is ideal for receiver testing, margin testing, and comprehensive signal verification tasks, delivering accuracy and performance in demanding environments.
Testwall can supply the used Anritsu MP1810A-015, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MP1810A-015.
