Anritsu MS2667C
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 13.2 GHz |
| Resolution Bandwidth | 1 Hz to 3 MHz (in 1-3-10 steps) |
| Display Average Noise Level | -148 dBm (typical) at 1 GHz, 10 Hz RBW |
| Phase Noise | -98 dBc/Hz at 1 GHz, 10 kHz offset (typical) |
| Input Impedance | 50 Ohms |
| Maximum Input Level | +30 dBm (1 W) |
| Amplitude Measurement Range | -148 dBm to +30 dBm |
| Frequency Reference Accuracy | ±0.3 ppm (aging per year) |
| Video Bandwidth | 1 Hz to 3 MHz |
| Power Supply | AC 100-240 V, 50/60 Hz |
Anritsu MS2667C Options:
- MS2667C - 02 - Narrow resolution bandwidth (30 Hz, 100 Hz, 300 Hz)
- MS2667C - 03 - Narrow resolution bandwidth (10 Hz, 30 Hz, 100 Hz, 300 Hz)
- MS2667C - 04 - High-speed time domain sweep
- MS2667C - 06 - Trigger/gate circuit
- MS2667C - 07 - AM/FM demodulator (outputs to loudspeaker or earphone connector)
- MS2667C - 10 - Centronics interface (GPIB interface cannot be installed simultaneously)
- MS2667C - 15 - Sweep signal output
| Model | MS2667C |
|---|
The Anritsu MS2667C is a compact, lightweight spectrum analyzer with a frequency range of 9 kHz to 30 GHz. It delivers superior performance with a high carrier-to-noise ratio, low distortion, and precise frequency/level accuracy. At just 15 kg, this analyzer is designed for portability without compromising measurement quality, offering reliable operation across a wide spectrum of applications.
Its simple interface makes it user-friendly while providing advanced analysis for millimeter applications. With multiple configuration options, it supports diverse measurement needs at a cost-effective level, making it ideal for both lab and field environments.
Testwall can supply the used Anritsu MS2667C, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MS2667C.
