Anritsu MS4642B
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 20 GHz |
| Number of Ports | 2-Port Vector Network Analyzer |
| Dynamic Range | Up to 130 dB |
| Output Power Range | -45 dBm to +3 dBm |
| Trace Noise | 0.004 dB RMS (at 10 Hz IF bandwidth) |
| IF Bandwidth | 1 Hz to 100 kHz |
| Number of Data Points | 2 to 100,001 points per sweep |
| Connector Type | Type-N (f), 50 Ohm |
| Display | 10.4-inch color LCD touchscreen |
| Interface/Connectivity | GPIB, USB, LAN (Ethernet) |
Anritsu MS4642B Options:
- MS4642B - 001 - Rack Mount, adds handles and removes feet for shelf-mounting into a 19" universal rack
- MS4642B - 002 - Time Domain
- MS4642B - 004 - Additional Serial-ATA (SATA) Solid State Drive (SSD) with OS and VectorStar Application Software
- MS4642B - 007 - Receiver Offset
- MS4642B - 031 - Dual Source Architecture
- MS4642B - 035 - IF Digitizer
- MS4642B - 041 - Noise Figure, requires Option 051, 061, or 062
- MS4642B - 042 - PulseView™, requires Option 035
- MS4642B - 043 - DifferentialView™
- MS4642B - 051 - Direct Access Loops, not available with Options 061 or 062
- MS4642B - 061 - Active Measurements Suite, with 2 Step Attenuators
- MS4642B - 062 - Active Measurements Suite, with 4 Step Attenuators
- MS4642B - 070 - 70 kHz Low-End Frequency Extension
- MS4642B - 098 - Z540/Guide 25 Calibration, No Data
- MS4642B - 099 - Premium Calibration, With Data
| Model | MS4642B |
|---|
The Anritsu MS4642B, part of the VectorStar VNA series, offers frequency coverage from 70 kHz to 20 GHz in a single coaxial port. It provides high-precision S-parameter measurement with a dynamic range up to 135 dB, output power to +10 dBm, and advanced calibration support via 12-term SOLT using the 3652A kit. Engineered for demanding applications, it ensures minimal measurement uncertainty and excellent repeatability for research and industrial needs.
With its broad span and support for AutoCal, the MS4642B is ideal for aerospace, wireless, and high-frequency component modeling. It also supports on-wafer and component-level testing, making it versatile for lab and production environments.
Testwall can supply the used Anritsu MS4642B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MS4642B.
