Anritsu MS8606A
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 3 GHz |
| Display | 8.4-inch color TFT LCD touchscreen |
| Dynamic Range | Up to 90 dB |
| Measurement Functions | Spectrum analysis, signal analysis, digital modulation analysis, analog modulation analysis |
| Resolution Bandwidth (RBW) | 1 Hz to 3 MHz |
| Phase Noise | -95 dBc/Hz at 10 kHz offset (typical) |
| Input Impedance | 50 Ohms |
| Power Supply | AC 100–240 V, 50/60 Hz; DC 11–32 V (battery operation supported) |
| Dimensions (W x H x D) | Approximately 310 mm x 238 mm x 88 mm |
| Weight | Approximately 5.5 kg (including battery) |
| Model | MS8606A |
|---|
The Anritsu MS8606A is a versatile transmission analyzer supporting CDMA (IS-95, ARIB STD-T53) and PDC standards. It measures frequency, waveform quality, timing error, code domain power, transmitter power, occupied bandwidth, spurious emissions, and bit error rates with precision. Equipped with a spectrum analyzer covering 10 MHz to 3 GHz, it is ideal for R&D, offering general-purpose evaluation functions for adjacent channel power, sideband noise, and occupied bandwidth in radio equipment. Additional features include frequency range of 300 kHz–3 GHz, high-speed accuracy, FM/øM, AF oscillator, and audio analyzer (optional).
This instrument is suited for transmitter testing, modulation accuracy checks, and FM radio transmission analysis, ensuring detailed and reliable performance evaluation across wireless communication standards.
Testwall can supply the used Anritsu MS8606A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MS8606A.
