Anritsu MT8510B
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 3 GHz |
| Measurement Functions | Power, Frequency, VSWR, Return Loss, Cable Loss, Distance-to-Fault (DTF) |
| Dynamic Range | Up to 85 dB |
| Distance-to-Fault Range | Up to 2000 meters (depending on cable type) |
| Display | 7-inch color TFT LCD touchscreen |
| Data Points | Up to 1001 data points per sweep |
| Battery Life | Approximately 3.5 hours with internal battery pack |
| Connector Type | N-type (female) RF connector |
| Operating Temperature | -10°C to +55°C (14°F to 131°F) |
| Weight | Approximately 2.3 kg (5.1 lbs) including battery |
Anritsu MT8510B Options:
- MT8510B - MT8510B-13 - Voice Codec Board
- MT8510B - MT8510B-23 - Voice Codec Board Retrofit
- MT8510B - MT8510B-14 - Wide Dynamic Range Board
- MT8510B - MT8510B-24 - Wide Dynamic Range Board Retrofit
- MT8510B - MX851000B - W-CDMA Measurement Software (requires MX851050B)
- MT8510B - MX851000B-01 - W-CDMA Voice Codec (requires MT8510B-13, MX851000B, and MX851050B)
- MT8510B - MX851001B - GSM Measurement Software
- MT8510B - MX851001B-01 - GSM Voice Codec (requires MT8510B-13 and MX851001B)
- MT8510B - MX851030B - Wide Dynamic Range (requires MT8510B-14; MX851000B and MX851050B for W-CDMA, MX851001B for GSM)
- MT8510B - MX851050B - W-CDMA Call Processing Software (requires MX851000B)
- MT8510B - MT8510B-ES310 - Extended Warranty Service (Three years)
- MT8510B - MT8510B-ES510 - Extended Warranty Service (Five years)
| Model | MT8510B |
|---|
The Anritsu MT8510B is a cellular communications analyzer designed for verifying RF integrity and testing mobile network equipment. It supports measurements such as channel power, adjacent channel power ratio, and wideband RF scanning. Engineered with automated test sequences and integrated calibration functions, it is ideal for both production and service environments.
Its protocol adaptability enables accurate analysis of GSM, TDMA, and other RF systems. The portable form factor makes it equally suited for field deployment and manufacturing applications.
Testwall can supply the used Anritsu MT8510B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MT8510B.
