Anritsu MT9080A
| Attribute | Value |
|---|---|
| Measurement Wavelength Range | 800 nm to 1700 nm |
| Dynamic Range | Up to 46 dB |
| Distance Range | Up to 256 km |
| Display | 5.7-inch color LCD touchscreen |
| Battery Life | Approximately 8 hours of continuous operation |
| Optical Connector Interface | Interchangeable adapter (FC, SC, ST, LC compatible) |
| Data Storage | Internal memory plus USB and SD card external storage |
| Communication Interfaces | USB, Ethernet (LAN), SD card slot |
| Operating Temperature | -10°C to +50°C |
| Weight | Approximately 1.5 kg (including battery) |
| Model | MT9080A |
|---|
The Anritsu MT9080A ACCESS Master OTDR is a compact, rugged handheld instrument designed for FTTx metro and access fiber network testing. It supports dual-wavelength single‑mode testing at 1310 nm and 1550 nm, offering a short 1 m event dead-zone and 5 cm sampling resolution for precise fault detection. At just 2.2 kg, it integrates an OTDR, optical power meter, light source, and fiber identifier in one portable unit, with internal memory for 1,000+ traces and USB support up to 30,000 waveforms.
Its menu-driven GUI ensures intuitive operation, with quick startup (~15 sec) and optional Ethernet IP testing including ping, traceroute, and throughput without requiring a PC. A modular visible light source option enhances fiber fault localization.
Testwall can supply the used Anritsu MT9080A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MT9080A.
