Anritsu
Anritsu S820E
Sitemaster, Cable and Antenna Analyser, up to 40 GHz (option dependent)
2 MHz to 20 GHz Frequency Range
Cable and Antenna Analyzer (Site Master) Measurement Type
0 to 65 dB Return Loss Range
1.00 to 65.00 VSWR Range
Up to 3000 meters (cable dependent) Distance-To-Fault (DTF) Range
| Attribute | Value |
|---|---|
| Frequency Range | 2 MHz to 20 GHz |
| Measurement Type | Cable and Antenna Analyzer (Site Master) |
| Return Loss Range | 0 to 65 dB |
| VSWR Range | 1.00 to 65.00 |
| Distance-To-Fault (DTF) Range | Up to 3000 meters (cable dependent) |
| Dynamic Range | Greater than 90 dB |
| Output Power | 0 dBm (nominal) |
| Display | 7-inch sunlight-readable color LCD touchscreen |
| Battery Life | Approximately 4 hours with standard Li-Ion battery pack |
| Operating Temperature | -10°C to +55°C (14°F to 131°F) |
| Model | S820E |
|---|
The Anritsu S820E is a rugged handheld spectrum and cable analyzer supporting measurements up to 6 GHz. It integrates return loss, VSWR, DTF, and spectrum functions, with a daylight‑readable display and intuitive controls, offering precise diagnostics for wireless infrastructure in the field.
Designed for antenna verification, cable certification, and RF maintenance, the device provides USB export, a touch/key interface, and rugged housing for reliable field use.
Testwall can supply the used Anritsu S820E, fully tested. With expert support and global delivery, Testwall ensures high‑performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu S820E.
