California Instruments 2750L
| Attribute | Value |
|---|---|
| Power Output | 2750 VA |
| Output Voltage Range | 0 – 300 VAC |
| Output Frequency Range | 45 – 500 Hz |
| Number of Phases | Single Phase |
| Input Voltage | 105 – 132 VAC / 210 – 264 VAC (50/60 Hz) |
| Output Current (Max) | 11.5 A RMS |
| Voltage Regulation | 0.1% of full scale |
| Total Harmonic Distortion (THD) | Less than 0.5% at full resistive load |
| Programming Interface | IEEE-488 (GPIB) / RS-232 |
| Form Factor | Rack Mountable, 3U |
California Instruments 2750L Single Phase Input, 3 Phase Output 3kW AC PSU Options:
- 2750L - 160 - Rtca/Do-160 Test Routines
- 2750L - 1M - Single Phase - Manual Controller
- 2750L - 1P - Single Phase - Standard Programmable Controller
- 2750L - 1PT - Single Phase - Fast Real-Time Servo Controller
- 2750L - 210960 - Rack Slides
- 2750L - 3M - Three Phase - Manual Controller
- 2750L - 3P - Three Phase - Standard Programmable Controller
- 2750L - 3PT - Three Phase - Fast Real-Time Servo Controller
- 2750L - 704 - Mil-Std-704 Test Routines
- 2750L - AX - Separate Isolated 26 Vac Regulated And 5 Vac Unregulated Outputs.
- 2750L - EHV - Extra High Voltage. Changes Output Transformer To 200V / 400V, L-N (1KHZ Max)
- 2750L - HV - High Voltage. Changes Output Transformer To 156V / 312V, L-N
- 2750L - LKM - Clock/Lock Master Unit.
- 2750L - LKS - Clock/Lock Slave Unit.
- 2750L - LV - Low Voltage. Changes Output Transformer To 67.5V / 135V, L-N.
- 2750L - MODE - Ieee Or Switch For Single-Phase Or Three Phase Output
- 2750L - MT - For Military Applications, W/ Ciil And Full Confidence Test
- 2750L - RPV - 10V Analog Programming
- 2750L - UP - 3-Phase L-L Voltage From 342 V To 456 V, L-L
| Model | 2750L |
|---|
The California Instruments 2750L features a single-phase input with three-phase output in a compact L-Series frame, delivering 3 kW of power across standard voltage ranges of 0–135 V and 0–270 V. It supports 17 Hz to 5 kHz frequencies, provides up to 22.2 Arms at 135 V, and maintains AC noise below 160 mV.
With its programmable controller and IEEE-488 bus interface, the 2750L simplifies automated testing routines using Abbreviated Plain English or ATLAS-based commands. It offers optional 26 V and 5 V auxiliary outputs for avionics, supports single- and three-phase configurations, and features automatic remote calibration and self-contained operation for seamless integration in production, QA, and ATE environments.
