California Instruments XDS600-8
| Attribute | Value |
|---|---|
| Power Output | 600 VA |
| Number of Phases | Single Phase |
| Output Voltage Range | 0 to 300 VAC |
| Output Frequency Range | 45 Hz to 500 Hz |
| Output Current (Max) | 8 A |
| Input Voltage | 105 to 132 VAC / 210 to 264 VAC (50/60 Hz) |
| Total Harmonic Distortion (THD) | Less than 0.5% at full linear load |
| Voltage Regulation | ±0.1% from no load to full load |
| Programming Interface | GPIB and RS-232 |
| Form Factor | Rack Mountable, 2U |
California Instruments XDS600-8 Options:
- XDS600-8 - -IF - GPIB / IEEE-488 interface programming option
- XDS600-8 - -400 - 400 ±10% volt line to line AC input
- XDS600-8 - -480 - 480 ±10% volt line to line AC input
- XDS600-8 - -AUX - Auxiliary control
- XDS600-8 - -RPV5 - Remote voltage programming, 0-5V
- XDS600-8 - -RPV10 - Remote voltage programming, 0-10V
- XDS600-8 - -RPC5 - Remote current programming, 0-5V
- XDS600-8 - -RPC10 - Remote current programming, 0-10V
| Model | XDS600-8 |
|---|
California Instruments XDS600-8 DC Power Supply
The California Instruments XDS600-8 DC Power Supply is a compact and powerful power supply that can deliver upto 600 volts and 8 amps of continuous power. Despite the high power density of this design, the XDS600-8 provides a low noise, stable output. With excellent output regulation and accuracy, California Instruments XDS600-8 DC Power Supply supports a wide variety of DC power applications including communications, semiconductors, automotive, information technology and industrial.
California Instruments XDS600-8 DC Power Supply is easy to operate with it's simple menu driven operation and familiar rotary controls for setting voltage and current. XDS600-8 comes with Windows GUI software. This GUI program offers additional functionalities like Output Sequencing, Data Logging and Pass/Fail Testing. The standard RS232C serial interface supports remote control of all power supply functions and measurements and allows for easy integration into ATE systems. An optional GPIB interface is available as well. Overall California Instruments XDS600-8 is a reliable and versatile DC Power Supply that can meet the demanding needs of a variety of applications.
Specifications for the California Instruments XDS600-8 DC Power Supply Include:
| Voltage | 0-600 Volts |
| Current | 0-8 Amps |
| Accuracy | 1.0 V |
| RMS Noise | 250mv |
