Crystal Engineering XP2I-15
| Attribute | Value |
|---|---|
| Pressure Range | 0 to 15 PSI |
| Accuracy | ±0.1% of full scale |
| Display | 4-digit LCD display |
| Pressure Units | Multiple units including PSI, bar, mbar, kPa, MPa, inHg, mmHg, inH2O, cmH2O |
| Power Supply | 9V alkaline battery |
| Battery Life | Up to 2000 hours of continuous use |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Pressure Type | Gauge pressure |
| Wetted Materials | 316L stainless steel |
| Pressure Port Connection | 1/4 NPT male |
Crystal Engineering XP2I-15 Options:
- XP2I-15 - DD - Dual Display
- XP2I-15 - S2 - 0.02% of Full Scale accuracy (15 to 25°C), 0.05% of Full Scale (-10 to 15°C, 25 to 50°C typical)
- XP2I-15 - S5 - 0.05% of Full Scale accuracy (-10 to 50°C)
- XP2I-15 - BSP - G 1/4 B BSP adapter type
- XP2I-15 - M20 - M20x1.5 adapter type
- XP2I-15 - RP - Back connection location
- XP2I-15 - F4 - Panel Mount connection
- XP2I-15 - DL - DataLogging
- XP2I-15 - AXX - System A pump system (0 to 30 psi/2 bar, pneumatic hand pump), aluminum case
- XP2I-15 - AHX - System A pump system (0 to 580 psi/40 bar, pneumatic hand pump), aluminum case
- XP2I-15 - BXX - System B pump system (-25 inHg to 30 psi, pneumatic hand pump), aluminum case
- XP2I-15 - BHX - System B pump system (-27 inHg to 580 psi, pneumatic hand pump), aluminum case
- XP2I-15 - CXX - System C pump system (0 to 3000 psi/200 bar, hydraulic oil hand pump), aluminum case
- XP2I-15 - CHX - System C pump system (0 to 5000 psi/350 bar, hydraulic oil hand pump), aluminum case
- XP2I-15 - DOX - System D pump system (0 to 5000 psi/350 bar, hydraulic oil bench top), aluminum case
- XP2I-15 - DWX - System D pump system (0 to 5000 psi/350 bar, hydraulic water bench top), aluminum case
- XP2I-15 - EOX - System E pump system (0 to 10,000 psi/700 bar, hydraulic oil bench top), aluminum case
- XP2I-15 - FOV - System F pump system (0 to 15,000 psi/1000 bar, hydraulic oil bench top), aluminum case
- XP2I-15 - FWV - System F pump system (0 to 15,000 psi/1000 bar, hydraulic water bench top), aluminum case
- XP2I-15 - GOX - System G pump system (0 to 15,000 psi/1000 bar, hydraulic oil bench top), waterproof case
- XP2I-15 - GWX - System G pump system (0 to 15,000 psi/1000 bar, hydraulic water bench top), waterproof case
- XP2I-15 - HOX - System H pump system (-27 inHg to 580 psi pneumatic and 0 to 5000 psi hydraulic oil), waterproof case
- XP2I-15 - W - Waterproof carrying case (Pelican Case)
| Model | XP2I-15 |
|---|
The Crystal Engineering XP2I-15 Digital Pressure Gauge delivers 0.1% reading accuracy, an ultra-rugged build, and intrinsic safety. Featuring a 0–15 psi range, 32,000 data point storage, and a long-life battery with ultra-low power mode, it ensures reliable performance even under extreme conditions. Its polycarbonate lens and elastomer-mounted circuitry guarantee durability against drops, shocks, and submersion.
With three simple buttons and no complicated menus, the XP2I-15 is user-friendly while maintaining full temperature compensation for consistent accuracy. Its flexibility allows use across wide pressure and temperature ranges, replacing multiple conventional gauges.
Testwall can supply the used Crystal Engineering XP2I-15, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Crystal Engineering XP2I-15.
