Crystal Engineering XP2I-30
| Attribute | Value |
|---|---|
| Pressure Range | 0 to 30 PSI |
| Accuracy | ±0.1% of full scale |
| Display | 4-digit LCD display |
| Pressure Units | PSI, bar, mbar, kPa, MPa, inHg, mmHg, inH2O, cmH2O, kg/cm² |
| Battery Life | Approximately 2000 hours of continuous use |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Pressure Port Connection | 1/4 inch NPT male |
| Overpressure Limit | 2x full scale (60 PSI) |
| Power Source | 9V alkaline battery |
| Housing/Enclosure Rating | IP67 rated, dust and water resistant |
Crystal Engineering XP2I-30 Options:
- XP2I-30 - -DD - Dual Display
- XP2I-30 - -S2 - 0.02% of Full Scale accuracy (15 to 25°C), 0.05% of Full Scale accuracy (-10 to 15°C, 25 to 50°C typical)
- XP2I-30 - -S5 - 0.05% of Full Scale accuracy (-10 to 50°C)
- XP2I-30 - -BSP - G 1/4 B BSP adapter type
- XP2I-30 - -M20 - M20x1.5 adapter type
- XP2I-30 - -RP - Back connection location
- XP2I-30 - -F4 - Panel mount connection location
- XP2I-30 - -DL - DataLogging (32,000 data points, non-volatile flash memory)
- XP2I-30 - -AXX - System A pump system (0 to 30 psi/2 bar, pneumatic hand pump), aluminum case
- XP2I-30 - -AHX - System A pump system (0 to 580 psi/40 bar, pneumatic hand pump), aluminum case
- XP2I-30 - -BXX - System B pump system (-25 inHg to 30 psi, pneumatic hand pump), aluminum case
- XP2I-30 - -BHX - System B pump system (-27 inHg to 580 psi, pneumatic hand pump), aluminum case
- XP2I-30 - -CXX - System C pump system (0 to 3000 psi/200 bar, hydraulic oil hand pump), aluminum case
- XP2I-30 - -CHX - System C pump system (0 to 5000 psi/350 bar, hydraulic oil hand pump), aluminum case
- XP2I-30 - -DOX - System D pump system (0 to 5000 psi/350 bar, hydraulic oil bench top), aluminum case
- XP2I-30 - -DWX - System D pump system (0 to 5000 psi/350 bar, hydraulic water bench top), aluminum case
- XP2I-30 - -EOX - System E pump system (0 to 10,000 psi/700 bar, hydraulic oil bench top), aluminum case
- XP2I-30 - -FOV - System F pump system (0 to 15,000 psi/1000 bar, hydraulic oil bench top), aluminum case
- XP2I-30 - -FWV - System F pump system (0 to 15,000 psi/1000 bar, hydraulic water bench top), aluminum case
- XP2I-30 - -GOX - System G pump system (0 to 15,000 psi/1000 bar, hydraulic oil bench top), waterproof Pelican case
- XP2I-30 - -GWX - System G pump system (0 to 15,000 psi/1000 bar, hydraulic water bench top), waterproof Pelican case
- XP2I-30 - -HOX - System H pump system (-27 inHg to 580 psi pneumatic and 0 to 5000 psi/350 bar hydraulic oil), waterproof Pelican case
- XP2I-30 - -W - Waterproof carrying case (Pelican case, available for Systems A, B, C, G, and H)
| Model | XP2I-30 |
|---|
The Crystal Engineering XP2I-30 Digital Pressure Gauge is an ultra-rugged, intrinsically safe device with 0.1% reading accuracy. It operates across a 0 to 30 psi range and can log up to 32,000 data points. Its long battery life, ultra-low power mode, and polycarbonate lens with elastomer-mounted circuitry ensure durability, shock resistance, and year-round operation without external power.
Designed for demanding environments, the XP2I-30 can withstand drops, submersion, and over-pressurization while maintaining accuracy. It features a simple three-button interface, making it easy to use without complex menus, while offering full temperature compensation and the ability to act as an intrinsically safe data recorder.
Testwall can supply the used Crystal Engineering XP2I-30 Digital Pressure Gauge, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Crystal Engineering XP2I-30 Digital Pressure Gauge.
