EA Elektro-Automatik ELR12000-40
| Attribute | Value |
|---|---|
| Input Voltage Range | 0 - 2000 V DC |
| Maximum Input Current | 0 - 40 A |
| Maximum Power | 12000 W (12 kW) |
| Operating Modes | CV, CC, CP, CR |
| Interface / Communication | USB, Analog Interface, optional: CAN, EtherCAT, Profibus, CANopen |
| Energy Recovery Efficiency | Up to 96% energy fed back into the AC mains grid |
| AC Input Supply | 3-phase, 400 V AC (±10%), 50/60 Hz |
| Cooling Method | Forced air cooling (internal fans) |
| Form Factor | 19-inch rack mount, 4U |
| Protection Features | Overvoltage (OVP), Overcurrent (OCP), Overpower (OPP), Overtemperature (OTP) |
EA Elektro-Automatik ELR12000-40 Options:
- ELR12000-40 - 33200808 - Standard model (ordering number)
- ELR12000-40 - 33250808 - With water-cooling (WC)
- ELR12000-40 - 33208808 - US 208V model
- ELR12000-40 - 33258808 - US 208V model with water-cooling (US208V+WC)
| Model | ELR12000-40 |
|---|
ELEKTRO-AUTOMATIK ELR12000-40 DC Electronic Load
The ELR12000-40 regenerative DC electronic load from EA Elektro-Automatik boasts high power density and premium features not found on typical loads. The ELR12000-40 is a regenerative load that can sink (absorb) cur and recover up to 96% of that cur putting it back to the local power grid. The energy recovery function converts the supplied DC energy into a synchronous sine cur and feeds it back into the local grid, eliminating the usual heat dissipation to a minimum and saving energy costs at the same time. The large color TFT touch panel offers a diffe and intuitive kind of manual operation, compared to electronic load series of other manufacturers.
For purposes of testing all kinds of batteries, such as for example constant cur or constant resistance discharging, the Elektro-Automatik ELR12000-40 offers a battery test mode. This show extra values for elapsed testing time and consumed capacity (Ah). EA Power Control can be exported as Excel table in CSV format and analyzed later in MS Excel or similar tools and even visualized as a discharge diagram. A special feature is the comfortable, FPGA based, digital function and arbitrary generator. It enables to control and run user-customizable load profiles and can generate sine, square, saw tooth and ramp functions in arbitrary order. The ELR12000-40 offer a wide range AC input with 342 - 528 V AC, covering common international grid ratings between 380 V and 480 V.
Specifications for the ELEKTRO-AUTOMATIK ELR12000-40 DC Electronic Load Include:
| Voltage | 0 to 2000V |
| Current | 0 to 40A |
| Total Power | 30kW |
| Efficiency | up to 95.5% |
