Exfo
Exfo FOT-92A Optical Power Meter +10dBm - -70dBm .2dB.
Optical Power Meter +10dBm - -70dBm ?.2dB.
+10 dBm to -70 dBm Power Measurement Range
±0.2 dB Measurement Accuracy
InGaAs Detector Type
800 nm to 1700 nm Wavelength Range
850, 1300, 1310, 1490, 1550, 1625 nm Calibrated Wavelengths
| Attribute | Value |
|---|---|
| Power Measurement Range | +10 dBm to -70 dBm |
| Measurement Accuracy | ±0.2 dB |
| Detector Type | InGaAs |
| Wavelength Range | 800 nm to 1700 nm |
| Calibrated Wavelengths | 850, 1300, 1310, 1490, 1550, 1625 nm |
| Display Resolution | 0.01 dB / 0.001 nW–mW |
| Connector Interface | Universal 2.5 mm adapter (FC, SC, ST compatible) |
| Power Supply | 3 AA batteries or AC adapter |
| Battery Life | Approximately 200 hours of continuous use |
| Operating Temperature | -10°C to +50°C (14°F to 122°F) |
Exfo FOT-92A Optical Power Meter +10dBm - -70dBm .2dB. Options:
- FOT-92A - RS - RS-232 cable and application software
| Model | FOT-92A |
|---|
The FOT-92A Optical Power Meter is a and rugged Handheld unit for Power/loss testing of fiber-optic links and Components. The FOT-92A features a Germainium Detector, a range of +10dBm to -70dBm and an accuracy of ?.2dB.
