Exfo
Exfo IQS-1700
800nM Fiber Optic Optical Power Meter
1260 nm to 1650 nm Wavelength Range
Up to 70 dB Dynamic Range
-80 dBm to +10 dBm Measurement Range
±0.01 nm Wavelength Accuracy
±0.5 dB Power Accuracy
| Attribute | Value |
|---|---|
| Wavelength Range | 1260 nm to 1650 nm |
| Dynamic Range | Up to 70 dB |
| Measurement Range | -80 dBm to +10 dBm |
| Wavelength Accuracy | ±0.01 nm |
| Power Accuracy | ±0.5 dB |
| Spectral Resolution | 0.07 nm (typical) |
| Interface/Platform Compatibility | EXFO IQS-600 and IQS-500 mainframe platforms |
| Connector Type | FC/APC interchangeable adapter |
| Sweep Speed | Up to 100 nm/s |
| Application | Optical spectrum analysis for DWDM and CWDM network testing and characterization |
| Model | IQS-1700 |
|---|
The EXFO IQS-1700 is a 800 nM Fiber Optic Optical Power Meter
