Exfo
Exfo PM-1623
800nm Fiber Optic Optical Power Meter
800 nm to 1700 nm Wavelength Range
-70 dBm to +10 dBm Power Measurement Range
Universal 2.5 mm adapter (FC, SC, ST compatible) Connector Type
InGaAs Detector Type
±0.2 dB Measurement Uncertainty
| Attribute | Value |
|---|---|
| Wavelength Range | 800 nm to 1700 nm |
| Power Measurement Range | -70 dBm to +10 dBm |
| Connector Type | Universal 2.5 mm adapter (FC, SC, ST compatible) |
| Detector Type | InGaAs |
| Measurement Uncertainty | ±0.2 dB |
| Display | Backlit LCD with dBm and mW readout |
| Battery Life | Approximately 200 hours with alkaline batteries |
| Power Supply | 2 x AA alkaline batteries |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Dimensions | 145 mm x 72 mm x 32 mm (5.7 in x 2.8 in x 1.3 in) |
| Model | PM-1623 |
|---|
