Exfo
Exfo PM-1623W
800nm Fiber Optic Optical Power Meter
1260 nm – 1650 nm Wavelength Range
-80 dBm to +10 dBm Power Measurement Range
InGaAs Detector Type
Universal 2.5 mm (FC, SC, ST compatible) Connector Type
Graphic LCD with backlight Display
| Attribute | Value |
|---|---|
| Wavelength Range | 1260 nm – 1650 nm |
| Power Measurement Range | -80 dBm to +10 dBm |
| Detector Type | InGaAs |
| Connector Type | Universal 2.5 mm (FC, SC, ST compatible) |
| Display | Graphic LCD with backlight |
| Measurement Uncertainty | ±0.2 dB |
| Battery Life | Approximately 200 hours with standard alkaline batteries |
| Power Supply | 3 x AA alkaline batteries or AC adapter |
| Operating Temperature | -10°C to +50°C (14°F to 122°F) |
| Standards Compliance | Calibrated to NIST-traceable standards; meets IEC 61010-1 |
| Model | PM-1623W |
|---|
