Exfo
Exfo PPM-350B
1310nm Fiber Optic Optical Power Meter
800 nm to 1700 nm Wavelength Range
-70 dBm to +10 dBm Power Measurement Range
±0.25 dB Power Measurement Uncertainty
InGaAs Detector Type
Universal 2.5 mm and 1.25 mm adapters Connector Interface
| Attribute | Value |
|---|---|
| Wavelength Range | 800 nm to 1700 nm |
| Power Measurement Range | -70 dBm to +10 dBm |
| Power Measurement Uncertainty | ±0.25 dB |
| Detector Type | InGaAs |
| Connector Interface | Universal 2.5 mm and 1.25 mm adapters |
| Display | Backlit LCD with simultaneous dBm and dB readings |
| Battery Life | Approximately 200 hours with standard AA batteries |
| Operating Temperature | -10°C to +50°C (14°F to 122°F) |
| Storage Temperature | -40°C to +70°C (-40°F to 158°F) |
| Dimensions | 160 mm x 76 mm x 38 mm (6.3 in x 3.0 in x 1.5 in) |
| Model | PPM-350B |
|---|
