Fluke 5725A
| Attribute | Value |
|---|---|
| Output Voltage Range | ±1100 V DC / ±1020 V AC (peak) |
| Output Current Range | ±220 mA DC / ±220 mA AC (peak) |
| DC Voltage Accuracy | ±(6 ppm of output + 2 ppm of range) |
| AC Voltage Frequency Range | 10 Hz to 500 kHz |
| DC Current Accuracy | ±(50 ppm of output + 10 ppm of range) |
| Resistance Output Range | 0 Ω to 1.1 MΩ |
| Power Amplifier Compatibility | Designed to work as a booster with Fluke 5700A/5720A series calibrators |
| Output Power | Up to 11 W (DC), up to 11 VA (AC) |
| Operating Temperature | 18 °C to 28 °C (64 °F to 82 °F) |
| Power Requirements | 100 V / 120 V / 220 V / 240 V AC, 48–66 Hz, 375 VA maximum |
| Model | 5725A |
|---|
The Fluke 5725A Amplifier significantly enhances AC and DC voltage and current performance when used with the 5700A Series calibrators. It extends AC output capabilities up to 750 V at 100 kHz and 1100 V at 30 kHz, supporting capacitive loads to 1000 pF. With current delivery of 70 mA above 5 kHz and 50 mA below, it enables calibration of demanding electronic devices with high accuracy.
This amplifier ensures reliable operation across wider ranges, making it suitable for precision calibration tasks in both laboratory and industrial environments.
Testwall can supply the used Fluke 5725A Amplifier, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Fluke 5725A Amplifier.
