Fluke 700P27
| Attribute | Value |
|---|---|
| Pressure Range | 0 to 3000 psi (0 to 200 bar) |
| Accuracy | ±0.05% of full scale |
| Pressure Type | Gauge |
| Output Signal | 0.01 mV/V/psi |
| Media Compatibility | Gas and liquid compatible with 316L stainless steel |
| Process Connection | 1/4 NPT male |
| Operating Temperature | -20°C to 85°C (-4°F to 185°F) |
| Compensated Temperature Range | 0°C to 50°C (32°F to 122°F) |
| Burst Pressure | 4500 psi (310 bar) |
| Wetted Materials | 316L stainless steel |
Fluke 700P27 Options:
- 700P27 - FLUKE-700P01 - Differential, 10 in. H2O / 0.01 range, Dry/Dry media, 316 SS fittings
- 700P27 - FLUKE-700P02 - Differential, 1 psi / 0.0001 range, Dry/Dry media, 316 SS fittings
- 700P27 - FLUKE-700P22 - Differential, 1 psi / 0.0001 range, 316 SS/Dry media, 316 SS fittings
- 700P27 - FLUKE-700P03 - Differential, 5 psi / 0.0001 range, Dry/Dry media, 316 SS fittings
- 700P27 - FLUKE-700P23 - Differential, 5 psi / 0.0001 range, 316 SS/Dry media, 316 SS fittings
- 700P27 - FLUKE-700P04 - Differential, 15 psi / 0.001 range, Dry/Dry media, 316 SS fittings
- 700P27 - FLUKE-700P24 - Differential, 15 psi / 0.001 range, 316 SS/Dry media, 316 SS fittings
- 700P27 - FLUKE-700P05 - Gage, 30 psi / 0.001 range, 316 SS media, 316 SS fittings
- 700P27 - FLUKE-700P06 - Gage, 100 psi / 0.01 range, 316 SS media, 316 SS fittings
- 700P27 - FLUKE-700P07 - Gage, 500 psi / 0.01 range, 316 SS media, 316 SS fittings
- 700P27 - FLUKE-700P08 - Gage, 1000 psi / 0.1 range, 316 SS media, 316 SS fittings
- 700P27 - FLUKE-700P09 - Gage, 1500 psi / 0.1 range, 316 SS media, 316 SS fittings
- 700P27 - FLUKE-700PA3 - Absolute, 5 psi / 0.0001 range, 316 SS media, 316 SS fittings
- 700P27 - FLUKE-700PA4 - Absolute, 15 psi / 0.001 range, 316 SS media, 316 SS fittings
- 700P27 - FLUKE-700PA5 - Absolute, 30 psi / 0.001 range, 316 SS media, 316 SS fittings
- 700P27 - FLUKE-700PA6 - Absolute, 100 psi / 0.01 range, 316 SS media, 316 SS fittings
- 700P27 - FLUKE-700PV3 - Vacuum, -5 psi / 0.0001 range, 316 SS/Dry media, 316 SS fittings
- 700P27 - FLUKE-700PV4 - Vacuum, -15 psi / 0.001 range, 316 SS/Dry media, 316 SS fittings
- 700P27 - FLUKE-700PD2 - Dual, ±1 psi / 0.0001 range, 316 SS/Dry media, 316 SS fittings
- 700P27 - FLUKE-700PD3 - Dual, ±5 psi / 0.0001 range, 316 SS/Dry media, 316 SS fittings
- 700P27 - FLUKE-700PD4 - Dual, ±15 psi / 0.001 range, 316 SS/Dry media, 316 SS fittings
- 700P27 - FLUKE-700PD5 - Dual, -15/30 psi / 0.001 range, 316 SS media, 316 SS fittings
- 700P27 - FLUKE-700PD6 - Dual, -15/100 psi / 0.01 range, 316 SS media, 316 SS fittings
- 700P27 - FLUKE-700PD7 - Dual, -15/200 psi / 0.01 range, 316 SS media, 316 SS fittings
- 700P27 - FLUKE-700P29 - High, 3000 psi / 0.1 range, Hastelloy C276 fittings
- 700P27 - FLUKE-700P30 - High, 5000 psi / 0.1 range, Hastelloy C276 fittings
- 700P27 - FLUKE-700P31 - High, 10000 psi / 1 range, Hastelloy C276 fittings
- 700P27 - FLUKE-700PCK - Pressure Calibration Kit (power supply, interface adapter, cables, and 700PC Pressure Module Calibration software)
- 700P27 - FLUKE-700PMP - Hand operated Pressure Pump, provides pressures up to approximately 150 psi (1000 kPa)
| Model | 700P27 |
|---|
Fluke 700P27 Gauge Pressure Module
The Fluke 700P27 Gauge Pressure Module allows to measure pressure with the Fluke 700 Series Process Calibrators. It displays pressure readings in any of 10 diffe pressure units specified in the calibrator setup. The pressure module has one pressure fitting and measures pressure with respect to atmospheric pressure. Fluke 700P27 Gauge Pressure Module is highly accurate and easy to operate. The calibrators automatically time-stamp and store all saved measurements, saving time, and eliminating errors associated with making manual notations in the field.
Fluke 700P27 Gauge Pressure Module features internal temperature compensation from 0 °C to 50 °C for full-accuracy performance. The pressure module measures pressure using an internal microprocessor. It receives operating power from and sends digital information to the calibrator. This module can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit, a PC, and a precision pressure source. Rugged urethane molded case of Fluke 700P27 Gauge Pressure Module protects the module from rough handling and harsh conditions.
Specifications for the Fluke 700P27 Gauge Pressure Module Include:
| Resolution | 0.01 / 0.1 |
| Measurement range | 300 psi / 2070 kPa |
| Reference Uncertainty (23 ± 3 °C) | 0.025 |
| Total Uncertainty 1 year | 0.05 |
