Fluke PM6654
| Attribute | Value |
|---|---|
| Frequency Range | 0.1 Hz to 160 MHz |
| Resolution | Up to 12 digits |
| Input Impedance | 1 MΩ / 50 Ω selectable |
| Sensitivity | 25 mV RMS (typical) |
| Time Base Accuracy | ±1 ppm aging per year |
| Gate Time | 1 ms to 1000 s |
| Input Voltage Range | Up to 200 V RMS (AC + DC) |
| Display | Vacuum Fluorescent Display (VFD), 12 digits |
| Interface | GPIB (IEEE-488) and RS-232 |
| Power Requirements | 100–240 V AC, 50/60 Hz |
| Model | PM6654 |
|---|
The Fluke PM6654 is a high-end, fully programmable timer and frequency counter with 2 ns (500 MHz) real-time clock resolution. It supports 14 versatile measurement modes, including frequency, period, voltage, pulse width, and phase, delivering up to 9 digits per second. With GPIB/IEEE‑488 programmability and high-speed data dump, it achieves 400–500 readings per second, ensuring reliable integration in automated test systems.
Designed for precision timing applications, the PM6654 offers outstanding speed, resolution, and flexibility, making it an ideal solution for laboratories and production environments.
Testwall can supply the used Fluke PM6654, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Fluke PM6654.
