Fluke 7340
| Attribut | Valeur |
|---|---|
| Plage de température | -45 °C à 150 °C |
| Précision | ±0,05 °C |
| Résolution | 0,001 °C |
| Stabilité | ±0,005 °C |
| Uniformité du bain | ±0,01 °C |
| Capacité du bain | 6 litres |
| Temps de chauffage | 45 minutes (de 25 °C à 150 °C) |
| Alimentation électrique | 230 V CA, 50/60 Hz |
| Puissance de chauffage | 1200 W |
| Dimensions (L x l x H) | 210 mm x 270 mm x 390 mm |
Fluke 7340 Options:
- 7340 - 230V - 230 VAC (±10%), 50 Hz, 8 amps optional power
- 7340 - IEEE-488 - IEEE-488 Interface (optional, RS-232 included as standard)
| Model | 7340 |
|---|
FLUKE 7340 Compact Temperature Calibration Baths
The Fluke 7340 Compact Temperature Calibration Bath is a versatile bench-top constant temperature bath ideal for temperature calibration and applications demanding precise temperature stability. It employs an advanced solid-state temperature controller with micro-controller technology to ensure precision thermometer testing, stability and uniformity.
The Fluke 7340 bath offers digital remote communication through standard RS-232 and optional IEEE-488 interfaces. The Fluke 7340 performs reliably across a wide temperature range from -40 °C to 150 °C, the refrigeration permits sub-ambient temperature control. Key features include rapid heating and cooling, temperature scan rate control, ramp and soak functions, memory for eight set-points, adjustable readout in C or F, and automatic refrigeration control.
Specifications for the FLUKE 7340 Compact Temperature Calibration Baths Include:
| Temperature Range | -40 C to 150 C |
| Heating Time | 25 C to 150 C (60 min) (oil 5012) |
| Cooling Time | 25 C to -40 C (110 min) (ethanol) |
| Digital Setting Accuracy | ± 0.5 C |
