Exfo
Exfo FTB200/8510B
10/100/1000 Ethernet Test System
1 260 nm – 1 650 nm Plage de longueur d'onde
jusqu'à 45 dB Plage dynamique
0,07 nm Résolution en longueur d'onde
± 0,01 nm Précision en longueur d'onde
jusqu'à 260 km Distance maximale de mesure
| Attribut | Valeur |
|---|---|
| Plage de longueur d'onde | 1 260 nm – 1 650 nm |
| Plage dynamique | jusqu'à 45 dB |
| Résolution en longueur d'onde | 0,07 nm |
| Précision en longueur d'onde | ± 0,01 nm |
| Distance maximale de mesure | jusqu'à 260 km |
| Largeur d'impulsion | 3 ns – 20 000 ns |
| Type de connecteur | FC/APC universel |
| Interface utilisateur | Plateforme FTB-200 avec écran tactile couleur |
| Alimentation | Batterie lithium-ion rechargeable / alimentation secteur CA |
| Normes de conformité | CEI 61010-1, CEI 60825-1 (Classe 1M) |
Exfo FTB200/8510B Options:
- FTB-880-FLEX - SONET - SONET testing
- FTB-880-FLEX - SDH - SDH testing
- FTB-880-FLEX - SONET-SDH - SONET and SDH testing
- FTB-880-FLEX - 155M - 155 Mbit/s transport rate (OC-3/STM-1)
- FTB-880-FLEX - 622M - 622 Mbit/s transport rate (OC-12/STM-4)
- FTB-880-FLEX - 2488M - 2.5 Gbit/s transport rate (OC-48/STM-16)
- FTB-880-FLEX - 9953M - 10 Gbit/s transport rate (OC-192/STM-64)
- FTB-880-FLEX - 00 - Without software options
- FTB-880-FLEX - DS3-G747 - G.747 test capability
- FTB-880-FLEX - DS1-FDL - DS1 FDL test capability
- FTB-880-FLEX - DUAL-RX - DS1/DS3 dual Rx testing
- FTB-880-FLEX - DS3-FEAC - DS3 FEAC test capability
- FTB-880-FLEX - TCM - Tandem connection monitoring
- FTB-880-FLEX - DSn - DSn test capability
- FTB-880-FLEX - PDH - PDH test capability
- FTB-880-FLEX - ISDN-PRI - ISDN primary rate interface
- FTB-880-FLEX - NI-CSU - NI-CSU loopback emulation
- FTB-880-FLEX - Cable_test - Cable test
- FTB-880-FLEX - IPV6 - Internet protocol version 6
- FTB-880-FLEX - ETH-THRU - Through mode capability
- FTB-880-FLEX - TRAFFIC_GEN - Traffic generation capability
- FTB-880-FLEX - CPRI-OBSAI - Enables 2.5 and 3.1 Gbit/s (requires SFP)
- FTB-880-FLEX - MPLS - Enables MPLS
- FTB-880-FLEX - 1588PTP - Generates and analyzes 1588 PTP
- FTB-880-FLEX - SyncE - Generates and analyzes SyncE protocol
- FTB-880-FLEX - TCP_THPUT - TCP throughput
- FTB-880-FLEX - OTU1 - OTN optical rate 2.666 Gbit/s
- FTB-880-FLEX - OTU2 - OTN optical rate 10.709 Gbit/s
- FTB-880-FLEX - OTU2-1e-2e - OTN optical rates 11.049/11.096 Gbit/s
- FTB-880-FLEX - OTU2-1f-2f - OTN optical rates 11.270/11.318 Gbit/s
- FTB-880-FLEX - FC1X - 1x Fibre Channel interface (requires SFP)
- FTB-880-FLEX - FC2X - 2x Fibre Channel interface (requires SFP)
- FTB-880-FLEX - FC4X - 4x Fibre Channel interface (requires SFP)
- FTB-880-FLEX - FC8X - 8x Fibre Channel interface (requires SFP+)
- FTB-880-FLEX - FC10X - 10x Fibre Channel interface (requires SFP+)
- FTB-880-FLEX - 100 OPTICAL - 100 Mbit/s optical Ethernet rate
- FTB-880-FLEX - GigE - 1000 Mbit/s optical and electrical Ethernet rate
- FTB-880-FLEX - 10G LAN - 10 GigE LAN interface
- FTB-880-FLEX - 10G WAN - 10 GigE WAN interface
- FTB-880-FLEX - FTB-8590 - SFP module GigE/FC/2FC, CPRI/OBSAI 2.45/3.07 Gbit/s at 850 nm, MM, <500 m
- FTB-880-FLEX - FTB-85910 - SFP modules 100 Base-FX, 1340 nm, MM, 2 km
- FTB-880-FLEX - FTB-85911 - SFP modules 100 Base-LX10, 1310 nm, SM, 15 km
- FTB-880-FLEX - FTB-85912 - SFP modules GigE/FC/2FC/4FC at 850 nm, <500 m
- FTB-880-FLEX - FTB-8190 - SFP module; rates: 155/622 Mbit/s, 2.5/2.7 Gbit/s, GigE/FC/2FC, CPRI/OBSAI 2.45/3.07 Gbit/s at 1310 nm, LC connector, 15 km reach
- FTB-880-FLEX - FTB-8191 - SFP module; rates: 155/622 Mbit/s, 2.5/2.7 Gbit/s, GigE/FC/2FC; CPRI/OBSAI 2.45/3.07 Gbit/s at 1310 nm, LC connector, 40 km reach
- FTB-880-FLEX - FTB-8192 - SFP module; rates: 155/622 Mbit/s, 2.5/2.7 Gbit/s, GigE/FC/2FC; 1550 nm, LC connector, 80 km reach
- FTB-880-FLEX - FTB-8193 - SFP module; rates: 155/622 Mbit/s, 2.5/2.7 Gbit/s, GigE/FC/2FC; 1550 nm, LC connector, 40 km reach
- FTB-880-FLEX - FTB-85913 - SFP modules GigE/FC/2FC/4FC at 1310 nm, 4 km
- FTB-880-FLEX - FTB-85914 - SFP modules GigE/FC/2FC/4FC at 1310 nm, 30 km
- FTB-880-FLEX - FTB-85915 - SFP modules GigE/FC/2FC/4FC at 1550 nm, <50 km
- FTB-880-FLEX - FTB-8690 - SFP+ modules 10FC/10 GigE at 850 nm, MM, 300 m
- FTB-880-FLEX - FTB-8691 - SFP+ modules 10 GigE at 1310 nm, 10 km
- FTB-880-FLEX - FTB-8693 - SFP+ modules 9.953-10.709/11.3, 8FC/10FC/10 GigE at 1310 nm, SMF, 10 km
- FTB-880-FLEX - FTB-8694 - SFP+ modules 8FC/10FC/10 GigE at 1550 nm, 40 km
- FTB-880-FLEX - FTB-8695 - SFP+ modules 8FC/10FC/10 GigE at 1550 nm, 80 km
- FTB-880-FLEX - FTB-8596 - SFP modules bidirectional 1490 Tx 1310 Rx 1000 BASE-BX10
- FTB-880-FLEX - FTB-8597 - SFP modules bidirectional 1310 Tx 1490 Rx 1000 BASE-BX10
- FTB-880-FLEX - FTB-8598 - SFP modules bidirectional 1310 Tx 1490/1550 Rx 1000 BASE-BX
- FTB-880-FLEX - FTB-8599 - SFP modules bidirectional 1550 Tx 1310 Rx 1000 BASE-BX
| Model | FTB200/8510B |
|---|
FTB-8510B Packet Blazer Bundled with the FTB-200 Mainframe
The FTB-8510 Packet Blazer brings performance assurance to Ethernet-based frame services. It offers all the test and measurement functionalities required to meet service-level agreements (SLAs) between service providers and their customers. This FTB-housed module tests transparent connectivity in its native format: 10/100/1000Base-T, 1000Base-SX, 1000Base-LX and 1000Base-ZX for LAN-to-LAN services delivered via ATM, frame relay, Next-Generation SONET/SDH, SONET/SDH hybrid multiplexers, switched Ethernet, VLANs, dark fiber, WDM or other means. It is capable of performing RFC-2544 testing.
If you are looking for a new or well-maintained used Exfo - FTB-8510B 10/100/1000 Ethernet test module refurbished with warranty, contact us or request a quote today.
