Rigol
Rigol DS4014E
High quality 4 channel DSO with 100 MHz bandwidth, 2 GSa/s (per channel) and 14 Mpts memory depth (per channel).
100 MHz Bande passante
4 voies analogiques Nombre de voies
2 GSa/s Taux d'échantillonnage en temps réel
14 Mpts Profondeur mémoire
8 bits Résolution verticale
| Attribut | Valeur |
|---|---|
| Bande passante | 100 MHz |
| Nombre de voies | 4 voies analogiques |
| Taux d'échantillonnage en temps réel | 2 GSa/s |
| Profondeur mémoire | 14 Mpts |
| Résolution verticale | 8 bits |
| Taille de l'écran | 7 pouces (TFT LCD couleur) |
| Résolution de l'écran | 800 × 480 pixels |
| Fréquence de mise à jour de la forme d'onde | 110 000 formes d'onde par seconde |
| Sensibilité verticale | 1 mV/div à 10 V/div |
| Interfaces de connectivité | USB Host, USB Device, LAN (LXI), port auxiliaire |
| Model | DS4014E |
|---|
The Rigol DS4014E is a very high quality four channel digital storage oscilloscope. It offers a real-time sample rate of up to 2 GSa/s (per channel) and and a bandwidth of up to 100 MHz.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The DS4012 has a refresh rate of up to 110.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
Other advantages: 9" color LCD, bright and vivid waveform display; versatile trigger modes: i.e. slope, alternative, rise&fall edge, enables users to stabilize the signal more easily. In economic context, the DS4012 clearly has the highest performance standard and the largest number of functions, making it a top of the range oscilloscope.
Attention: All DS/MSO4000 are equipped with a new fan which is much more quiet than before!
