Rigol
Rigol MSO2102A
100 MHz Mixed Signal Oscilloscope
100 MHz Bande passante
2 voies Nombre de voies analogiques
16 voies Nombre de voies numériques
1 GSa/s Taux d'échantillonnage en temps réel
14 Mpts Profondeur mémoire
| Attribut | Valeur |
|---|---|
| Bande passante | 100 MHz |
| Nombre de voies analogiques | 2 voies |
| Nombre de voies numériques | 16 voies |
| Taux d'échantillonnage en temps réel | 1 GSa/s |
| Profondeur mémoire | 14 Mpts |
| Taille de l'écran | 7 pouces TFT LCD (800 x 480 pixels) |
| Taux de capture des formes d'onde | jusqu'à 50 000 formes d'onde/s |
| Résolution verticale | 8 bits |
| Plage de sensibilité verticale | 1 mV/div à 10 V/div |
| Interface de communication | USB Host, USB Device, LAN (LXI), Aux |
| Model | MSO2102A |
|---|
The MSO2000A series digital oscilloscope is another Best-In-Class instrument from Rigol offering an unmatched feature/value package. The MSO2000A is a fast and versatile scope covering frequencies up to 300 MHz with two channels and a wide vertical range (500uV/div-10V/div) to deliver an extremely low noise floor to help you capture smaller signals. Add a 2 GSa/s max. sample rate and 14 Mpts. of standard memory depth to its user-friendly interface and 8 inch WVGA display and you've got a scope that outperforms the competition in a wide range of bench-top and field applications. The MSO2000A series also includes 16 bit of mixed signal logic channels as well as an option for an embedded 2 channel, 25 MHz waveform generator.
