Rigol
Rigol MSO4022
200 MHz Mixed Signal Oscilloscope
200 MHz Bande passante
2 Nombre de voies analogiques
16 Nombre de voies numériques
2 GSa/s Taux d'échantillonnage maximal
56 Mpts Profondeur mémoire
| Attribut | Valeur |
|---|---|
| Bande passante | 200 MHz |
| Nombre de voies analogiques | 2 |
| Nombre de voies numériques | 16 |
| Taux d'échantillonnage maximal | 2 GSa/s |
| Profondeur mémoire | 56 Mpts |
| Résolution verticale | 8 bits |
| Taille de l'écran | 7 pouces (écran tactile couleur) |
| Taux de capture des formes d'onde | 500 000 formes d'onde/s |
| Sensibilité verticale | 1 mV/div à 10 V/div |
| Interface de communication | USB Host, USB Device, LAN (LXI), HDMI |
Rigol MSO4022 Options:
- MSO4022 - SD-RS232-DS4000 - RS232/UART Decoding Kit
- MSO4022 - SD-I2C/SPI-DS4000 - I2C/SPI Decoding Kit
- MSO4022 - SD-CAN-DS4000 - CAN Decoding Kit
- MSO4022 - SD-FlexRay-DS4000 - FlexRay Decoding Kit
- MSO4022 - RP7150 - Active Differential Probe (1.5 GHz)
- MSO4022 - RM-DS4000 - Rack Mount Kit
| Model | MSO4022 |
|---|
The MSO4000 series digital oscilloscope is a versatile, high performance mixed signal oscilloscope that incorporates many of today?s most advanced technologies and processes. Featuring bandwidths between 100MHz and 500MHz, sample rates up to 4GSa/s, 2 or 4 analog channels, and 16 digital logic channels, the MSO4000 is ideal for a wide variety of engineers working in communications, defense, aerospace, industrial electronics, R&D and educational fields.
