Sorensen DCS60-50E
| Attribut | Valeur |
|---|---|
| Tension de sortie | 0 – 60 V |
| Courant de sortie | 0 – 50 A |
| Puissance de sortie maximale | 3000 W |
| Régulation de tension | 0,05% + 10 mV |
| Régulation de courant | 0,05% + 25 mA |
| Ondulation et bruit (tension) | 20 mV crête à crête |
| Interface de programmation | RS-232 / GPIB en option |
| Tension d'alimentation | 208/240 V CA, monophasé, 50/60 Hz |
| Dimensions (L x H x P) | 425 mm x 133 mm x 610 mm (3U) |
| Poids | 27 kg |
Sorensen DCS60-50E Options:
- DCS60-50E - M1 - Factory configured for 115 VAC input (1 kW and 1.2 kW units only)
- DCS60-50E - M9C - Internal IEEE-488/RS-232 Interface (can only support 12-bit slaves)
- DCS60-50E - M13 - Locking shafts (front panel potentiometers)
- DCS60-50E - M32 - Master/slave paralleling cable configured for two units
- DCS60-50E - M51A - Isolated analog programming control of V/I/OVP and isolated V/I monitor outputs up to 500V relative to the supply's return line
- DCS60-50E - M85 - 12-bit slave interface option for use with M9 or M130 master (3 ft. control cable included)
- DCS60-50E - M130 - LXI compliant 10/100 Base T Ethernet remote control master interface; includes web server for direct control of power supply via web browser (MS Internet Explorer 6.0 or later)
- DCS60-50E - M131 - 16-bit slave interface option for use with a M130 master (3 ft. control cable included)
- DCS60-50E - M133 - Output disconnect and polarity reversal relays controlled via SCPI commands. Limited to 1kW or 1.2 kW, ≤100V, ≤60A
- DCS60-50E - M135 - M130 & M133 combination. Limited to 1kW or 1.2 kW, ≤100V, ≤60A
- DCS60-50E - M136 - M131 & M133 combination. Limited to 1kW or 1.2 kW, ≤100V, ≤60A
| Model | DCS60-50E |
|---|
SORENSEN DCS60-50E Power Supply
The Sorensen DCS60-50E Power Supply is a 3kW programmable power supply which is ideally suited for a wide range of applications requiring DC power in a small form factor. Applications range from manufacturing test and burn-in of automotive components, avionics electronics, telecommunications and consumer products to beam steering, process control and laboratory R&D use. The DCS60-50E programmable power supply utilizes switchmode technology to achieve high power density in a low profile chassis.
The Sorensen DCS60-50E Power Supply includes a user-friendly platform that can be controlled from the front panel with 10-turn potentiometers to adjust voltage, cur and OVP settings. With the 16-bit resolution of the Ethernet programming and hardware triggering allows for detailed sequencing associated with battery fluctuation simulation. The tight load regulation capability included in the DCS60-50E power supply makes it a superior source for validation and acceptance testing and burn-in of automotive components. Margin testing of 12V and 14V nominal components, such as electronic control units (ECU) and electromechanical components, is easily achieved. The DCS60-50E power supply also provides a high accuracy voltage output to optimize battery charging.
Specifications for the SORENSEN DCS60-50E Power Supply Include:
| Voltage | 60 V |
| Current | 50 A |
| Power | 3,000 W |
