Tektronix DSA71604C
4 Ch 16 GHz Digital Signal Analyzer
16 GHz Largeur de bande passante
50 GS/s Taux d'échantillonnage
4 voies Nombre de voies
8 bits Résolution verticale
jusqu'à 250 Mpoints par voie Longueur d'enregistrement
| Attribut | Valeur |
|---|---|
| Largeur de bande passante | 16 GHz |
| Taux d'échantillonnage | 50 GS/s |
| Nombre de voies | 4 voies |
| Résolution verticale | 8 bits |
| Longueur d'enregistrement | jusqu'à 250 Mpoints par voie |
| Sensibilité verticale | 1 mV/div à 1 V/div |
| Temps de montée | 21,9 ps |
| Interface de connectivité | USB, LAN (LXI), GPIB |
| Système d'exploitation | Windows 7 |
| Affichage | Écran couleur LCD 15,3 pouces |
Tektronix DSA71604C Options:
- DSA71604C - 2XL - Extended record length – 31.25 MS/Ch (Standard on DSA70000)
- DSA71604C - 5XL - Extended record length – 62.5 MS/Ch
- DSA71604C - 10XL - Extended record length – 125 MS/Ch
- DSA71604C - 20XL - Extended record length – 250 MS/Ch
- DSA71604C - SSD - Additional Removable Disk – Solid State Drive
- DSA71604C - LT - Waveform Limit Testing
- DSA71604C - MTH - Mask testing for Serial Standards. Includes hardware clock recovery for up to 3.125 Gb/s (Standard on DSA70000)
- DSA71604C - ST6G - Protocol Triggering and Decoding for 8b/10b-encoded Serial Signals up to 6.25 Gb/s. Includes hardware clock recovery and pattern lock triggering (Standard on DSA70000)
- DSA71604C - D-PHY - MIPI D-PHY Essentials – Characterization and Analysis Solution
- DSA71604C - DDRA - DDR Memory Bus Analysis
- DSA71604C - DJA - DPOJET Jitter and Eye Diagram Analysis (Standard on DSA70000)
- DSA71604C - DSPT - DisplayPort Compliance Test Solution
- DSA71604C - DVI - DVI Compliance Test Solution
- DSA71604C - ERRDT - Frame and Bit Error Rate Detector for High-speed Serial Standards
- DSA71604C - ET3 - Ethernet Compliance Test Software
- DSA71604C - HT3 - HDMI Compliance Test Software
- DSA71604C - HT3DS - HDMI Direct Synthesis for HDMI 1.4
- DSA71604C - M-PHY - MIPI M-PHY Essentials – Characterization and Analysis Solution
- DSA71604C - PCE3 - PCI Express Gen3 Essentials
- DSA71604C - PWR - Power Measurement and Analysis Software
- DSA71604C - QPI - Intel Quick Path Interconnect Test Automation Software
- DSA71604C - SFP-TX - SFP+ Compliance and Debug Solution
- DSA71604C - SLA - Serial Data Link Analysis Advanced (with Equalization)
- DSA71604C - SLE - Serial Data Link Analysis Essentials (no Equalization)
- DSA71604C - SR-COMP - Computer Serial Triggering and Analysis (RS-232/422/485/UART)
- DSA71604C - SR-CUST - Custom Serial Analysis Kit for Developers
- DSA71604C - SR-DPHY - MIPI D-PHY (DSI / CSI2) Serial Analysis
- DSA71604C - SR-EMBD - Embedded Serial Triggering and Analysis (I2C, SPI)
- DSA71604C - SR-USB - USB Serial Triggering and Analysis
- DSA71604C - SVE - SignalVu Essentials – Vector Signal Analysis Software
- DSA71604C - SVM - General Purpose Modulation Analysis
- DSA71604C - SVO - Flexible OFDM Analysis
- DSA71604C - SVP - Advanced Signal Analysis (including pulse measurements)
- DSA71604C - SVT - Frequency and Phase Settling Time Measurements
- DSA71604C - USB - USB 2.0 Compliance Test Software
- DSA71604C - USB3 - USB 3.0 Compliance and Analysis Software
- DSA71604C - VET - Visual Trigger
- DSA71604C - TEKEXP - TekExpress Automation Framework
- DSA71604C - D-PHYTX - D-PHY Automated Solution
- DSA71604C - DIIVA - DiiVA Automation Solution
- DSA71604C - DP-SINK - DisplayPort Sink Compliance Automation Software
- DSA71604C - HEAC - HEAC Automated Solution
- DSA71604C - SAS-RSG - Stand-alone SAS Receiver Measurements
- DSA71604C - SAS-RXTX - Stand-alone SAS Channel Measurements
- DSA71604C - SAS-TSG - Stand-alone SAS Transmitter Measurements
- DSA71604C - SAS-DHB - Stand-alone SAS Bundled Solution
- DSA71604C - SATA-TSG - SATA PHY/TSG/OOB Transmitter Tests for TekExpress
- DSA71604C - SATA-RSG - SATA RSG/RMT Receiver Tests for TekExpress
- DSA71604C - SATA-RXTX - SATA Rx/Tx Channel Tests for TekExpress
- DSA71604C - SATA-DHB - SATA TekExpress SW Bundle (TSG, RSG, RXTX for Hosts or Devices)
- DSA71604C - SATA-SI - SATA SI Cable Tests for TekExpress
- DSA71604C - USB-RMT - TekExpress Automated USB 3.0 Receiver Solution
- DSA71604C - USB-TX - TekExpress Automated USB 3.0 Solution
- DSA71604C - XGbT - 10GBASE-T Automated Solution
- DSA71604C - L0 - English manual
- DSA71604C - L1 - French manual
- DSA71604C - L3 - German manual
- DSA71604C - L5 - Japanese manual
- DSA71604C - L7 - Simple Chinese manual
- DSA71604C - L8 - Standard Chinese manual
- DSA71604C - L9 - Korean manual
- DSA71604C - L10 - Russian manual
- DSA71604C - L99 - No manual
- DSA71604C - A0 - US plug, 115 V, 60 Hz
- DSA71604C - A1 - Euro plug, 220 V, 50 Hz
- DSA71604C - A2 - UK plug, 240 V, 50 Hz
- DSA71604C - A3 - Australian plug, 240 V, 50 Hz
- DSA71604C - A5 - Swiss plug, 220 V, 50 Hz
- DSA71604C - A6 - Japanese plug, 100 V, 110/120 V, 60 Hz
- DSA71604C - A10 - China plug, 50 Hz
- DSA71604C - A11 - India plug, 50 Hz
- DSA71604C - A12 - Brazilian plug, 60 Hz
- DSA71604C - A99 - No power cord
- DSA71604C - C3 - Calibration Service 3 Years
- DSA71604C - C5 - Calibration Service 5 Years
- DSA71604C - D1 - Calibration Data Report
- DSA71604C - D3 - Calibration Data Report 3 Years (with Opt. C3)
- DSA71604C - D5 - Calibration Data Report 5 Years (with Opt. C5)
- DSA71604C - G3 - Complete Care 3 Years (includes loaner, scheduled calibration and more)
- DSA71604C - G5 - Complete Care 5 Years (includes loaner, scheduled calibration and more)
- DSA71604C - R3 - Repair Service 3 Years
- DSA71604C - R5 - Repair Service 5 Years
- DSA71604C - IF - Upgrade Installation Service
| Model | DSA71604C |
|---|
Le Tektronix DSA71604C est un analyseur numérique série à bande passante de 16 GHz, doté de 4 canaux, d'une fréquence d’échantillonnage de 100 GS/s et d’une mémoire standard de 31 Mpts. Il garantit une intégrité de signal supérieure et un rapport signal‑bruit exceptionnel pour une représentation d’onde vraie. Il inclut le déclenchement Pinpoint® et Visual, le déclenchement série en temps réel à 6,25 Gb/s, la fonction Search & Mark, et prend en charge I2C, SPI, USB 2.0 et MIPI® D‑PHY.
Conçu pour les standards série haute vitesse, RF large bande et analyse mémoire, il offre précision, automatisation et efficacité utilisateur grâce à ses options applicatives dédiées.
Testwall peut fournir le Tektronix DSA71604C d’occasion, entièrement testé. Avec un support expert et une livraison mondiale, Testwall garantit un instrument de haute performance, fiabilité et qualité de service inégalées. Merci de nous contacter directement si vous avez besoin d’une calibration ou réparation du Tektronix DSA71604C.
