Teledyne LeCroy HDO9104
High Definition Oscilloscope, 1 GHz, 4 Ch, 10-bit, 20 GS/s, 64 Mpts/Ch
1 GHz Bande passante
4 Nombre de voies
2,5 GS/s Taux d'échantillonnage
12 bits Résolution verticale
250 Mpts/voie Mémoire d'acquisition
| Attribut | Valeur |
|---|---|
| Bande passante | 1 GHz |
| Nombre de voies | 4 |
| Taux d'échantillonnage | 2,5 GS/s |
| Résolution verticale | 12 bits |
| Mémoire d'acquisition | 250 Mpts/voie |
| Taille de l'écran | 12,1 pouces (écran tactile capacitif) |
| Sensibilité verticale | 1 mV/div à 1 V/div |
| Base de temps | 200 ps/div à 1 ks/div |
| Bruit du système | Moins de 1 mV RMS (1 mV/div) |
| Connectivité | USB, Ethernet, DisplayPort |
Teledyne LeCroy HDO9104 Options:
- HDO9104 - HDO9K-256GB-RSSD - 256 GB Removable Solid State Drive Option
- HDO9104 - HDO9K-256GB-RSD-02 - Additional 256 GB Solid State Drive for use with RSSD option. Includes Microsoft Windows 7 For Embedded Systems 64Bits, Teledyne LeCroy Oscilloscope Software and Critical Scope Operational File Duplicates
- HDO9104 - HDO9K-8CH-SYNCH - Hardware kit to allow for 8 channel synch capability to combine 2 HDO9000 High Definition Oscilloscopes
- HDO9104 - HDO9K-1553 TD - MIL-STD-1553 Trigger and Decode Option
- HDO9104 - HDO9K-1553 TDME - MIL-STD-1553 Trigger, Decode, Measure/Graph, and Eye Diagram Option
- HDO9104 - HDO9K-80B-8b10b TD - 8b10b Decode Option - Includes 80 bit 3.125 Gb/s serial trigger
- HDO9104 - HDO9K-Audiobus TD - AudioBus Trigger and Decode Option
- HDO9104 - HDO9K-Audiobus TDG - AudioBus trigger, decode, and graph Option
- HDO9104 - HDO9K-ARINC429BUS DSYMBOLIC - ARINC 429 Bus Symbolic Decode Option
- HDO9104 - HDO9K-ARINC429BUS DME SYMBOLIC - ARINC 429 Bus Symbolic Decode, Measure/Graph, and Eye Diagram Option
- HDO9104 - HDO9K-CAN FDBUS TD - CAN FD Trigger and Decode Option
- HDO9104 - HDO9K-CAN FDBUS TDME - CAN FD Trigger, Decode, Measure/Graph, and Eye Diagram Option
- HDO9104 - HDO9K-CAN FDBUS TDME SYMBOLIC - CAN FD Symbolic Trigger, Decode, and Measure/Graph, and Eye Diagram Option
- HDO9104 - HDO9K-CANBUS TD - CAN Trigger and Decode Option
- HDO9104 - HDO9K-CANBUS TDME - CAN Trigger, Decode, Measure/Graph, and Eye Diagram Option
- HDO9104 - HDO9K-CANBUS TDME SYMBOLIC - CAN Symbolic Trigger, Decode, and Measure/Graph, and Eye Diagram Option
- HDO9104 - HDO9K-DigRF3Gbus D - DigRF 3G Bus Decode Option
- HDO9104 - HDO9K-DigRFV4bus D - DigRF V4 Bus Decode Option
- HDO9104 - HDO9K-DPHYbus D - MIPI D-PHY CSI-2, DSI Bus Decode Option
- HDO9104 - HDO9K-DPHYbus DP - MIPI D-PHY CSI-2, DSI Bus Decode and Physical Layer Test Option
- HDO9104 - HDO9K-ENETbus D - ENET Bus Decode Option
- HDO9104 - HDO9K-EMB TD - Bundle: Includes I2C, SPI, UART-RS232 Trigger and Decode Option
- HDO9104 - HDO9K-EMB TDME - Bundle: Includes I2C, SPI, UART-RS232 Trigger, Decode, Measure/Graph, and Eye Diagram Option
- HDO9104 - HDO9K-FCbus D - FibreChannel decode annotation Option
- HDO9104 - HDO9K-FLEXRAYBUS TD - FlexRay Trigger and Decode Option
- HDO9104 - HDO9K-FLEXRAYBUS TDMP - FlexRay Trigger, Decode, Measure/Graph and Physical Layer Option
- HDO9104 - HDO9K-I2CBUS TD - I2C Trigger and Decode Option
- HDO9104 - HDO9K-I2CBUS TDME - I2C Trigger, Decode, Measure/Graph, and Eye Diagram Option
- HDO9104 - HDO9K-LINBUS TD - LIN Trigger and Decode Option
- HDO9104 - HDO9K-LINBUS TDME - LIN Trigger, Decode, Measure/Graph, and Eye Diagram Option
- HDO9104 - HDO9K-MANCHESTERbus D - Manchester Bus Decode Option
- HDO9104 - HDO9K-MPHYbus D - MIPI M-PHY Bus Decode Option
- HDO9104 - HDO9K-MPHYbus DP - MIPI M-PHY Bus Decode and Physical Layer Test Option
- HDO9104 - HDO9K-NRZbus D - NRZ Bus Decode Option
- HDO9104 - HDO9K-PCIebus D - PCIe Gen 1 Decode Option
- HDO9104 - HDO9K-PROTOBUS MAG - Serial Debug Toolkit - Measure Analyze Graph Option
- HDO9104 - HDO9K-ProtoSync - Decode Annotation and Protocol Analyzer Synchronization Option
- HDO9104 - HDO9K-ProtoSync-BT - Decode Annotation and Protocol Analyzer+Bit Tracer Synchronization Option
- HDO9104 - HDO9K-SASbus D - SAS Decode annotation Option
- HDO9104 - HDO9K-SATAbus TD - SATA Trigger and Decode Option
- HDO9104 - HDO9K-SENTbus D - SENT Bus Decode Option
- HDO9104 - HDO9K-SPACEWIREbus D - SpaceWire Decode Option
- HDO9104 - HDO9K-SPIBUS TD - SPI Trigger and Decode Option
- HDO9104 - HDO9K-SPIBUS TDME - SPI Trigger, Decode, Measure/Graph, and Eye Diagram Option
- HDO9104 - HDO9K-SPMIbus D - SPMI Decode Option
- HDO9104 - HDO9K-UART-RS232BUS TD - UART-RS232 Trigger and Decode Option
- HDO9104 - HDO9K-UART-RS232BUS TDME - UART-RS232 Trigger, Decode, Measure/Graph, and Eye Diagram Option
- HDO9104 - HDO9K-UNIPRObus D - MIPI UniPro Protocol Decoder Software Option
- HDO9104 - HDO9K-UPG-MPHY-UNIPRObus D - MPHY to UniPro Decoder Software Upgrade (MPHY Required)
- HDO9104 - HDO9K-USB2-HSICbus D - USB 2.0 HSIC Decode Option
- HDO9104 - HDO9K-USB2BUS TD - USB 2.0 Trigger and Decode Option
- HDO9104 - HDO9K-USB2BUS TDME - USB 2.0 Trigger, Decode, Measure/Graph, and Eye Diagram Option
- HDO9104 - QPHY-BroadR-Reach - QualiPHY Enabled BroadR-Reach Software Option
- HDO9104 - QPHY-ENET - QualiPHY Enabled Ethernet 10/100/1000BT Software Option
- HDO9104 - QPHY-DDR2 - QualiPHY Enabled DDR2 Software Option
- HDO9104 - QPHY-DDR3 - QualiPHY Enabled DDR3 Software Option
- HDO9104 - QPHY-LPDDR2 - QualiPHY Enabled LPDDR2 Software Option
- HDO9104 - QPHY-MIPI-DPHY - QualiPHY Enabled MIPI D-PHY Software Option
- HDO9104 - QPHY-MOST150 - QualiPHY Enabled MOST150 Software Option
- HDO9104 - QPHY-MOST50 - QualiPHY Enabled MOST50 Software Option
- HDO9104 - QPHY-USB - QualiPHY Enabled USB 2.0 Software Option
- HDO9104 - HDO9K-CBL-DE-EMBED - Cable De-Embedding Option
- HDO9104 - HDO9K-EYEDRII - Eye Doctor II (Virtual Probe and Equalizer Emulation Bundle)
- HDO9104 - HDO9K-SDM - Serial Data Mask Software Option
- HDO9104 - HDO9K-SDAII - SDAII Serial Data Analysis Option
- HDO9104 - HDO9K-DDR2-TOOLKIT - DDR2 and LPDDR2 Debug Toolkit
- HDO9104 - HDO9K-DDR3-TOOLKIT - DDR3, DDR3L, LPDDR3, DDR2, and LPDDR2 Debug Toolkit
- HDO9104 - HDO9K-UPG-DDR3-TOOLKIT - DDR3, DDR3L, LPDDR3, DDR2, and LPDDR2 Debug Toolkit Upgrade
- HDO9104 - HDO9K-AORM - Advanced Optical Recording Measurement Package
- HDO9104 - HDO9K-DDM2 - Disk Drive Measurements Software Package
- HDO9104 - HDO9K-DDA - Disk Drive Analyzer Software Package
- HDO9104 - HDO9K-PWR - Power Analyzer Software Option
- HDO9104 - HDO9K-VECTORLINQ - VectorLinQ – Flexible vector signal analysis for electrical signals (RF and baseband I-Q)
- HDO9104 - HDO9K-JITKIT - Clock, Clock-Data Jitter Analysis And Views Of Time, Statistical, Spectral, and Jitter Overlay
- HDO9104 - HDO9K-XDEV - Advanced Customization Option
- HDO9104 - HDO9K-EMC - EMC Pulse Parameter Software Option
- HDO9104 - HDO9K-ETPMT - Electrical Telecom Mask Test Software Option
- HDO9104 - HDO9K-Q-SCAPE - Q-Scape Multi-tab Display Option
- HDO9104 - HDO9K-SPECTRUM - Spectrum Analyzer and Advanced FFT Option
- HDO9104 - HDO9K-DFP2 - Digital Filter Software Option
- HDO9104 - HDO9K-RACK - Rackmount, 8U Adaptor Kit
| Model | HDO9104 |
|---|
Le Teledyne LeCroy HDO9104 est un oscilloscope haute définition avec une bande passante analogique de 1 GHz et quatre canaux d’entrée. Il dispose d’une résolution verticale 12-bits, garantissant une fidélité du signal supérieure aux oscilloscopes 8-bits traditionnels. Avec des taux d’échantillonnage allant jusqu’à 10 GS/s et des options de mémoire profonde flexibles, il capture des formes d’onde précises dans des environnements de test exigeants.
Cet oscilloscope est idéal pour les diagnostics de signaux analogiques basse vitesse, audio et de précision, offrant une capture de signal propre et une analyse détaillée dans de multiples applications.
Testwall peut fournir le Teledyne LeCroy HDO9104 High-Definition Oscilloscope d’occasion, entièrement testé. Avec un support expert et une livraison mondiale, Testwall garantit un instrument hautes performances avec une fiabilité et une qualité de service inégalées. Veuillez nous contacter si vous avez besoin de calibration ou de réparation du Teledyne LeCroy HDO9104 High-Definition Oscilloscope.
