Teledyne LeCroy HDO9204
2 GHz, 10-bit, 40 GS/s, 4 Ch, 64 Mpts/Ch High Definition Oscilloscope w/ 15.4" WXGA Color Display
2 GHz Bande passante
4 voies analogiques Nombre de voies
10 GS/s (voie unique), 5 GS/s (toutes voies) Taux d'échantillonnage
12 bits Résolution verticale
jusqu'à 250 Mpts/voie Mémoire d'acquisition
| Attribut | Valeur |
|---|---|
| Bande passante | 2 GHz |
| Nombre de voies | 4 voies analogiques |
| Taux d'échantillonnage | 10 GS/s (voie unique), 5 GS/s (toutes voies) |
| Résolution verticale | 12 bits |
| Mémoire d'acquisition | jusqu'à 250 Mpts/voie |
| Taille de l'écran | 12,1 pouces, écran tactile couleur HD |
| Sensibilité verticale | 1 mV/div à 1 V/div |
| Plage de temps de balayage | 200 ps/div à 800 s/div |
| Entrées numériques (MSO) | 16 voies logiques (en option) |
| Connectivité | USB, Ethernet, DisplayPort, HDMI |
