Vectawave VBA400-150
High Power Amplifier, 10kHz - 400MHz, 150W
400 MHz – 1000 MHz Plage de fréquences
150 W Puissance de sortie nominale
≥ 50 dB Gain typique
0 dBm Puissance d'entrée maximale
50 Ω Impédance d'entrée/sortie
| Attribut | Valeur |
|---|---|
| Plage de fréquences | 400 MHz – 1000 MHz |
| Puissance de sortie nominale | 150 W |
| Gain typique | ≥ 50 dB |
| Puissance d'entrée maximale | 0 dBm |
| Impédance d'entrée/sortie | 50 Ω |
| Connecteurs RF | Type N femelle |
| Alimentation électrique | 220 – 240 V CA, 50/60 Hz |
| Mode de fonctionnement | Continu (CW) et modulé |
| Protection intégrée | Protection contre les surcharges et les courts-circuits en sortie |
| Format mécanique | Rack 19 pouces |
Vectawave VBA400-150 Options:
- VBA400-150 - OPT-GPIB - USB/GPIB Interface (Optional)
- VBA400-150 - OPT-RACK-FRONT - Rack mount with Front panel connectors
- VBA400-150 - OPT-RACK-REAR - Rack mount with Rear panel connectors
- VBA400-150 - OPT-BENCH - Bench mount with Front panel connectors
| Model | VBA400-150 |
|---|
VECTAWAVE VBA400-150 High Power Amplifier
The Vectawave VBA400-150 High Power Amplifier spaning frequency of 10kHz to 400MHz, is tailored for EMC applications. This amplifier utilizes robust push-pull MOSFET technology to ensure exceptional even order harmonic suppression. Operating in class A, it offers minimal distortion and a remarkable tolerance for 100% mismatch, rendering fold-back protection unnecessary. These attributes make the Vectawave VBA400-150 an excellent choice for the most demanding transducer needs, emphasizing its robustness and adaptability for general linear power requirements.
Specifications for the VECTAWAVE VBA400-150 High Power Amplifier Include:
| Frequency Range | 10 kHz to 400 MHz |
| Rated Output Power | 150 W Min |
| Output Power Harmonics | Better than -20dBc @ 75W |
| Output Impedence | 50 Ohms |
