Glassman
Glassman LP60-46
60V 46A 2800W DC Supply
60 kV Output Voltage
46 mA Output Current
2,760 W Output Power
105–125 VAC / 210–250 VAC, 50/60 Hz Input Voltage
Positive Output Polarity
| Attribute | Value |
|---|---|
| Output Voltage | 60 kV |
| Output Current | 46 mA |
| Output Power | 2,760 W |
| Input Voltage | 105–125 VAC / 210–250 VAC, 50/60 Hz |
| Output Polarity | Positive |
| Voltage Regulation (Line/Load) | 0.01% or 3 V, whichever is greater |
| Current Regulation (Line/Load) | 0.01% or 2 mA, whichever is greater |
| Ripple | 0.01% RMS or 30 mV RMS, whichever is greater |
| Operating Temperature Range | 0°C to 50°C |
| Cooling Method | Forced Air (Internal Fan) |
| Model | LP60-46 |
|---|
The Glassman LP60-46 is a high-performance DC power supply delivering 60V at 46A with a total output of 2800W, engineered for applications demanding precision and power stability.
This unit offers robust output regulation, low ripple, and excellent transient response, ideal for industrial, laboratory, and development environments.
Testwall can supply the used Glassman LP60-46, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Glassman LP60-46.
