Haefely PIM150
| Attribute | Value |
|---|---|
| Test Frequency Range | 700 MHz – 2700 MHz |
| Carrier Output Power | 2 x 20 W (43 dBm) |
| PIM Measurement Sensitivity | -107 dBm (typical) |
| IM Order Tested | 3rd Order Intermodulation (IM3) |
| Connector Interface | 4.3-10 / 7-16 DIN |
| Test Standard Compliance | IEC 62037 / ETSI EN 150 129 |
| Operating Temperature Range | -10°C to +50°C |
| Power Supply | AC 100–240 V, 50/60 Hz |
| Display / Interface | Touchscreen LCD with integrated software interface |
| Weight | Approximately 12 kg (portable handheld unit) |
Haefely PIM150 Options:
- PIM150 - ADAPTERS - Single phase input & output adapters enable PIM 150 to be used for single phase applications
- PIM150 - WinFEAT&R - Control and reporting software. Runs under windows 98, NT, ME, 2000, XP
- PIM150 - Rack Mounting - Modules can be rack mounted for greater mechanical stability and mobility
- PIM150 - PCD150 - Coupling decoupling network for data and control lines according to IEC 61000-4-12 Ed.1 and IEC 61000-4-18 Ed.1
- PIM150 - IP4A - Capacitive coupling clamp as described in ANSI C37.90
- PIM150 - PIM110 - 100kHz Ring Wave module according to IEC 61000-4-12 Ed.1 and Ed.2
- PIM150 - AXOS5 - EFT generator according to IEC 61000-4-4 and ANSI C37.90
| Model | PIM150 |
|---|
The Haefely PIM150 is a high-voltage impulse generator engineered for precise insulation and dielectric testing. It delivers controlled discharges to assess dielectric strength and insulation performance under demanding conditions. With rugged construction and compliance to international standards, it ensures safe and reliable operation in labs and R&D facilities.
Ideal for research applications, the PIM150 supports accurate material analysis, performance evaluation, and durability testing. Its precision design makes it essential for environments where high-voltage testing is critical.
Testwall can supply the used Haefely PIM150, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Haefely PIM150.
