Hipotronics 2293
| Attribute | Value |
|---|---|
| Output Voltage | 100 kV AC |
| Output Current | 200 mA |
| Power Rating | 20 kVA |
| Frequency | 50/60 Hz |
| Input Voltage | 208/240 V AC |
| Test Type | High Potential (Hipot) AC Dielectric Testing |
| Voltage Regulation | Closed-loop automatic voltage regulation |
| Control Type | Digital microprocessor-based control panel |
| Safety Features | Overcurrent protection, emergency stop, interlock system |
| Compliance Standards | ANSI, IEEE, IEC dielectric test standards |
Hipotronics 2293 Options:
- 2293 - SKTTR - 3-phase transformer turns ratio measurement add on application for 2293
- 2293 - SKAP - Arbitrary phase shift add on application for the 2293 (2293/SKTTR needed)
- 2293 - SKTR - Heat rise add on application for the 2293
- 2293 - SKMB - Magnetic balance add on application for the 2293
- 2293 - SKTC - Tap changer test, dynamic resistance
- 2293 - SKSC - Short circuit impedance measurement at reduced current
- 2293 - TAP - Tap changer control
- 2293 - TEMP1 - Temperature probe for liquids
- 2293 - TEMP2 - Magnetic temperature probe
- 2293 - 10HV - Extension cable 10m High voltage side
- 2293 - 10LV - Extension cable 10m low voltage side
- 2293 - TEMPEXT - Temperature extension box to connect up to 8 additional temperature sensors (up to three extension boxes / 24 temperature inputs can be connected to a single 2293)
- 2293 - ITLOCK - Safety interlock plug to stop test from an external switch
| Model | 2293 |
|---|
The Hipotronics 2293 is a premium cable and insulation diagnostic analyzer designed for high-voltage systems. It provides accurate insulation resistance and tan delta measurements, with lightweight construction for portable field use. Engineers benefit from its precise dielectric loss evaluation and robust performance under demanding conditions.
This versatile unit supports diagnostics for power cables, transformers, and capacitors, offering real-time data display with a user-friendly interface. It enhances predictive maintenance, improves fault detection, and increases system reliability.
Testwall can supply the used Hipotronics 2293, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Hipotronics 2293.
