Isotech IPS-3610D
36V 3A DC Power Supply
3 Output Channels
0-36V (CH1 & CH2), 5V Fixed (CH3) Output Voltage Range
0-10A (CH1 & CH2), 3A Fixed (CH3) Output Current Range
756W Total Power Output
≤0.01% + 3mV Voltage Regulation (Load)
| Attribute | Value |
|---|---|
| Output Channels | 3 |
| Output Voltage Range | 0-36V (CH1 & CH2), 5V Fixed (CH3) |
| Output Current Range | 0-10A (CH1 & CH2), 3A Fixed (CH3) |
| Total Power Output | 756W |
| Voltage Regulation (Load) | ≤0.01% + 3mV |
| Current Regulation (Load) | ≤0.01% + 3mA |
| Ripple & Noise (Voltage) | ≤1mVrms |
| Display Type | 4-digit LED display for voltage and current |
| Operating Temperature | 0°C to 40°C |
| Input Voltage | 115V/230V AC, 50/60Hz |
| Model | IPS-3610D |
|---|
The series of switched mode power supplies have removed the inconvenience of big volumes and heavyweight associated with traditional power supplies. 36V output at 10A, 500W, 900VA
