Hameg
Hameg HM8112-3 Digital Precision Multimeter
4½ cifre (20000 conteggi) Numero di cifre del display
±0,03% ± 1 digit Precisione tensione DC
200 mV – 1000 V Intervallo di misura tensione DC
200 mV – 750 V Intervallo di misura tensione AC
200 µA – 10 A Intervallo di misura corrente DC
| Attributo | Valore |
|---|---|
| Numero di cifre del display | 4½ cifre (20000 conteggi) |
| Precisione tensione DC | ±0,03% ± 1 digit |
| Intervallo di misura tensione DC | 200 mV – 1000 V |
| Intervallo di misura tensione AC | 200 mV – 750 V |
| Intervallo di misura corrente DC | 200 µA – 10 A |
| Intervallo di misura resistenza | 200 Ω – 20 MΩ |
| Interfaccia di comunicazione | RS-232 |
| Alimentazione | 230 V AC, 50/60 Hz |
| Dimensioni (L x A x P) | 260 x 88 x 295 mm |
| Peso | 2,5 kg |
Hameg HM8112-3 Digital Precision Multimeter Options:
- HM8112-3 - HM8112-3S - HM8112-3 incl. Scanner Card (8+1 Channels each 2- and 4-Wire)
- HM8112-3 - HO112 - Scanner Card (Installation only ex factory)
- HM8112-3 - HO880 - Interface IEEE-488 (GPIB), galvanically isolated
| Model | HM8112-3 |
|---|
Hameg HM8112-3 6.5 -Digit Precision Multimeter.
This meter is of high performance and feature rich and still remarkably easy to use. It is durable and accurate and suitable for a wide variety of appliations, including research and development and manufacturing test.
In addition, the HM8112-3 also measures temperature.
Key Features
- 6?-digit display (1,200,000 counts)
- Resolution: 100nV, 100pA, 100??, 0.01?C/F
- DC basic accuracy 0.003%
- 2-wire/4-wire measurements
- Measurement intervals adjustable from 0.1?60 s
