Hameg
Hameg HMF2525 Arbitrary Function Generator
25 MHz Frequenza massima
2 Canali
200 MSa/s Frequenza di campionamento
14 bit Risoluzione verticale
256k punti per canale Memoria forme d'onda
| Attributo | Valore |
|---|---|
| Frequenza massima | 25 MHz |
| Canali | 2 |
| Frequenza di campionamento | 200 MSa/s |
| Risoluzione verticale | 14 bit |
| Memoria forme d'onda | 256k punti per canale |
| Impedenza di uscita | 50 Ω |
| Ampiezza di uscita | 10 mVpp – 10 Vpp (su 50 Ω) |
| Forme d'onda standard | Sinusoide, quadra, triangolare, rampa, impulso, rumore, DC e forme d'onda arbitrarie |
| Interfacce di comunicazione | USB (dispositivo e host), RS-232, IEEE-488 (GPIB opzionale) |
| Display | Display TFT a colori da 3,8 pollici |
Hameg HMF2525 Arbitrary Function Generator Options:
- HMF2525 - HO730 - Dual-Interface Ethernet/USB
- HMF2525 - HO740 - Interface IEEE-488 (GPIB), galvanically isolated
| Model | HMF2525 |
|---|
The HMF2525 is versatile, high performance function/arbitrary waveform generator with the largest arbitrary memory depth in its class. It combines the ability to produce nearly any conceivable arbitrary waveform with precision and accuracy. Frequency range 10mHz to 25MHz
This generator is suitable for a wide range of applications including electronic design, sensor simulation and functional test.
Key Features
- Arbitrary waveform generator: 250 Msample/s, 14 bit, 256 kpoint
- Sine, square, pulse, triangle, ramp, arbitrary waveforms incl. standard curves (white noise, cardiac, etc.)
- Burst, sweep, gating, external trigger
- Modulation modes: AM, FM, pulse, PWM, FSK (internal and external)
- DC offset: ?5 mV to 5 V
- Rise time < 8 ns
- 8.9 cm (3.5") TFT: crisp representation of waveform
- USB/RS-232 dual interface, optionally Ethernet/USB or IEEE 488 (GPIB)
