Pacific Power Source 140ASX
400VA AC Power Source
140 VA Potenza di uscita
0 – 300 V AC (monofase) Tensione di uscita
45 Hz – 500 Hz Frequenza di uscita
108 – 132 V AC / 216 – 264 V AC Tensione di ingresso
47 Hz – 63 Hz Frequenza di ingresso
| Attributo | Valore |
|---|---|
| Potenza di uscita | 140 VA |
| Tensione di uscita | 0 – 300 V AC (monofase) |
| Frequenza di uscita | 45 Hz – 500 Hz |
| Tensione di ingresso | 108 – 132 V AC / 216 – 264 V AC |
| Frequenza di ingresso | 47 Hz – 63 Hz |
| Forma d'onda | Sinusoidale pura |
| Distorsione armonica totale (THD) | Meno di 0,5% |
| Interfaccia di controllo | Pannello frontale con display digitale e interfaccia RS-232 |
| Dimensioni (L x A x P) | 133 mm x 133 mm x 381 mm (formato rack 3U) |
| Peso | Circa 9,1 kg |
Pacific Power Source 140ASX Options:
- 140ASX - UPC-1M - 1 Phase Manual Control 15 Hz to 1,200 Hz controller
- 140ASX - UPC-3M - 3 Phase Manual Control 15 Hz to 1,200 Hz controller
- 140ASX - UPC-1 - 1 Phase Programmable Control 15 Hz to 1,200 Hz controller
- 140ASX - UPC-3 - 3 Phase Programmable Control 15 Hz to 1,200 Hz controller
- 140ASX - GPIB - GPIB (IEEE-488.2) Interface with SCPI (optional on UPC-1 and UPC-3)
- 140ASX - PROG-Z - Programmable Output Impedance (optional on UPC-1 and UPC-3)
- 140ASX - WAVEFORM-SYN - Waveform Harmonic Synthesis – create AC test waveforms by building from harmonics up through the 51st (optional on UPC-1 and UPC-3)
- 140ASX - WAVEFORM-ANAL - Waveform Analysis (FFT) – harmonic analysis of voltage or current waveform up to the 51st harmonic (optional on UPC-1 and UPC-3)
- 140ASX - SLIDE-RAILS - Slide rails for 19-inch rack mounting (available as an option for all models)
- 140ASX - 480V-INPUT - 480 V input (available as a cost option)
- 140ASX - 400HZ-INPUT - 400 Hz input (available as a cost option)
- 140ASX - OUTPUT-MAGNETICS - Output Magnetics for alternate output voltage range (wide range of output magnetics for world-wide testing)
- 140ASX - UPC-STUDIO - UPC Studio compiled software suite for control, output sequence editing, and waveform editing
- 140ASX - LABVIEW-DRIVERS - LabView for Windows and LabWindows Instrument Drivers
| Model | Source |
|---|
The ASX Series is Pacific Power Source?s family of High Performance AC Power Sources ranging from 1.5kVA to 12kVA. Power conversion within the ASX Series is achieved by high frequency pulse width modulation, resulting in cool, quiet, and efficient operation.
