Rigol
Rigol DS2202E
High quality 2 channel DSO with 200 MHz bandwidth, 1 GSa/s (per Channel) and 28 Mpts memory depth (per Channel).
200 MHz Larghezza di banda
2 canali analogici Numero di canali
2 GSa/s (in tempo reale) Frequenza di campionamento
56 Mpts (standard) Profondità di memoria
8 bit Risoluzione verticale
| Attributo | Valore |
|---|---|
| Larghezza di banda | 200 MHz |
| Numero di canali | 2 canali analogici |
| Frequenza di campionamento | 2 GSa/s (in tempo reale) |
| Profondità di memoria | 56 Mpts (standard) |
| Risoluzione verticale | 8 bit |
| Dimensione del display | 8 pollici TFT LCD (800 x 480 pixel) |
| Frequenza di aggiornamento forma d'onda | fino a 50.000 forme d'onda al secondo |
| Gamma di tensione verticale | 1 mV/div - 10 V/div |
| Base dei tempi | 5 ns/div - 50 s/div |
| Interfacce di connettività | USB Host, USB Device, LAN (LXI), Aux Out |
| Model | DS2202E |
|---|
The Rigol DS2202E is a very high quality two channel digital storage oscilloscope. It features a real-time sample rate of up to 1 GSa/s per channel and a bandwidth of 200 MHz.
The Rigol oscilloscopes are equipped with well designed and easy to use controls offering comprehensive ease-of-use functions for all measuring tasks. The menu navigation is intuitive and available in several languages.
This high performance standard not only ensures capturing real-time instantaneous signals, but also observes details of repeated signals. The DS2202E has a refresh rate of up to 50.000 wfms/s, enabling users to capture instantaneous signals, as well as abnormal signals more quickly. It also helps to enhance the waveform capturing ability and to expedite a circuit debug course. The quality of the Rigol oscilloscopes is comparable to Agilent and Tektronix oscilloscopes.
The particularly large TFT color displays are very easy to read. Thanks to an intelligent system for displaying or masking information, the largest possible area is always available for displaying signals. The signal curves, the FFT display, and other functions can be shown simultaneously on the display.
