Rigol
Rigol MSO2072A
70 MHz Mixed Signal Oscilloscope
70 MHz Larghezza di banda
2 Canali analogici
16 Canali digitali
2 GSa/s Frequenza di campionamento massima
14 Mpts Profondità di memoria
| Attributo | Valore |
|---|---|
| Larghezza di banda | 70 MHz |
| Canali analogici | 2 |
| Canali digitali | 16 |
| Frequenza di campionamento massima | 2 GSa/s |
| Profondità di memoria | 14 Mpts |
| Risoluzione verticale | 8 bit |
| Dimensione dello schermo | 7 pollici TFT LCD (800 x 480 pixel) |
| Frequenza di aggiornamento della forma d'onda | fino a 50.000 forme d'onda al secondo |
| Interfacce di comunicazione | USB Host, USB Device, LAN (opzionale), RS232 (opzionale) |
| Tensione di ingresso massima | 300 V CAT I |
| Model | MSO2072A |
|---|
The MSO2000A series digital oscilloscope is another Best-In-Class instrument from Rigol offering an unmatched feature/value package. The MSO2000A is a fast and versatile scope covering frequencies up to 300 MHz with two channels and a wide vertical range (500uV/div-10V/div) to deliver an extremely low noise floor to help you capture smaller signals. Add a 2 GSa/s max. sample rate and 14 Mpts. of standard memory depth to its user-friendly interface and 8 inch WVGA display and you've got a scope that outperforms the competition in a wide range of bench-top and field applications. The MSO2000A series also includes 16 bit of mixed signal logic channels as well as an option for an embedded 2 channel, 25 MHz waveform generator.
